HarmonyOs应用《日记本》开发第21篇 - 列表渲染与 ForEach 循环
·
本篇深入分析鸿蒙 ArkUI 中的列表渲染机制,重点讲解 ForEach 和 LazyForEach 的使用方法与性能差异。

一、ForEach 基本用法
1.1 基本语法
ForEach(
arr: Array,
itemGenerator: (item: any, index?: number) => void,
keyGenerator?: (item: any, index?: number) => string
)
1.2 日记列表中的应用
List({ space: 12 }) {
ForEach(
this.diaries, // 数据源
(diary: DiaryInfo, index: number) => { // 子项生成器
ListItem() {
this.DiaryCard(diary)
}
},
(diary: DiaryInfo) => diary.id // 键值生成器
)
}
1.3 三个参数详解
| 参数 | 说明 | 必填 |
|---|---|---|
| 数据源 | 需要遍历的数组 | 是 |
| itemGenerator | 生成每个子项 UI 的函数 | 是 |
| keyGenerator | 生成唯一键值的函数 | 推荐 |
二、键值生成器的重要性
2.1 键值的作用
键值生成器是 ForEach 性能优化的关键。它帮助框架的 Diff 算法识别哪些项发生了变化:
// ✅ 正确:使用唯一 id 作为键值
ForEach(this.diaries, (diary: DiaryInfo) => {
ListItem() { this.DiaryCard(diary) }
}, (diary: DiaryInfo) => diary.id)
// ❌ 错误:使用 index 作为键值(不推荐)
ForEach(this.diaries, (diary: DiaryInfo, index: number) => {
ListItem() { this.DiaryCard(diary) }
}, (diary: DiaryInfo, index: number) => index.toString())
2.2 键值对性能的影响
数据更新:在列表头部插入新日记
使用 index 作为键值:
┌───┬───┬───┬───┐ ┌───┬───┬───┬───┬───┐
│ A │ B │ C │ D │ → │ N │ A │ B │ C │ D │
│ 0 │ 1 │ 2 │ 3 │ │ 0 │ 1 │ 2 │ 3 │ 4 │
└───┴───┴───┴───┘ └───┴───┴───┴───┴───┘
所有项的 key 都变了!框架重新渲染全部5项
使用 id 作为键值:
┌───┬───┬───┬───┐ ┌───┬───┬───┬───┬───┐
│ A │ B │ C │ D │ → │ N │ A │ B │ C │ D │
│a1 │b2 │c3 │d4 │ │n5 │a1 │b2 │c3 │d4 │
└───┴───┴───┴───┘ └───┴───┴───┴───┴───┘
只有 N 是新的!框架只渲染1项,其余复用
三、ForEach 常见场景
3.1 简单数组遍历
@State colors: string[] = ['#FF0000', '#00FF00', '#0000FF', '#FFFF00']
Row() {
ForEach(this.colors, (color: string) => {
Circle()
.width(40)
.height(40)
.fill(color)
}, (color: string) => color)
}
3.2 天气标签列表
@State weatherList: WeatherItem[] = [
{ label: '☀️ 晴', value: Weather.SUNNY },
{ label: '☁️ 阴', value: Weather.CLOUDY },
{ label: '🌧️ 雨', value: Weather.RAINY },
{ label: '⛅ 多云', value: Weather.PARTLY_CLOUDY },
{ label: '🌨️ 雪', value: Weather.SNOWY }
]
Flex({ wrap: FlexWrap.Wrap }) {
ForEach(this.weatherList, (item: WeatherItem, index: number) => {
Text(item.label)
.fontSize(16)
.padding(8)
.margin(4)
.borderRadius(20)
.backgroundColor(
this.selectedWeather === item.value ? '#007DFF' : '#F5F5F5'
)
.onClick(() => {
this.selectedWeather = item.value
})
}, (item: WeatherItem) => item.value.toString())
}
3.3 嵌套 ForEach
// 日记按月分组
ForEach(this.groupedDiaries, (monthGroup: MonthGroup) => {
// 月份标题
Text(monthGroup.month)
.fontSize(18)
.fontWeight(FontWeight.Bold)
// 该月下的日记列表
ForEach(monthGroup.diaries, (diary: DiaryInfo) => {
ListItem() {
this.DiaryCard(diary)
}
}, (diary: DiaryInfo) => diary.id)
}, (monthGroup: MonthGroup) => monthGroup.month)
四、LazyForEach 懒加载
4.1 为什么需要懒加载
当日记数量很大时(如数百上千条),ForEach 会一次性创建所有列表项,导致:
- 内存占用高
- 首次渲染慢
- 滑动卡顿
LazyForEach 只渲染可视区域内的项,按需加载:
// 实现 IDataSource 接口
class DiaryDataSource implements IDataSource {
private diaries: DiaryInfo[] = []
private listeners: DataChangeListener[] = []
totalCount(): number {
return this.diaries.length
}
getData(index: number): DiaryInfo {
return this.diaries[index]
}
registerDataChangeListener(listener: DataChangeListener): void {
this.listeners.push(listener)
}
unregisterDataChangeListener(listener: DataChangeListener): void {
const pos = this.listeners.indexOf(listener)
if (pos >= 0) {
this.listeners.splice(pos, 1)
}
}
setData(diaries: DiaryInfo[]): void {
this.diaries = diaries
this.notifyDataReload()
}
notifyDataReload(): void {
this.listeners.forEach(listener => {
listener.onDataReloaded()
})
}
}
4.2 使用 LazyForEach
@State diaryDataSource: DiaryDataSource = new DiaryDataSource()
List({ space: 12 }) {
LazyForEach(this.diaryDataSource, (diary: DiaryInfo) => {
ListItem() {
this.DiaryCard(diary)
}
}, (diary: DiaryInfo) => diary.id)
}
4.3 ForEach vs LazyForEach
| 特性 | ForEach | LazyForEach |
|---|---|---|
| 渲染策略 | 一次性渲染全部 | 按需渲染可见项 |
| 数据源 | 普通数组 | IDataSource 接口 |
| 适用场景 | 少量数据(<100项) | 大量数据(>100项) |
| 内存占用 | 高 | 低 |
| 滑动性能 | 可能卡顿 | 流畅 |
| 实现复杂度 | 简单 | 需要实现接口 |
五、列表项动画
5.1 添加/删除动画
List() {
ForEach(this.diaries, (diary: DiaryInfo) => {
ListItem() {
this.DiaryCard(diary)
}
.transition({
type: TransitionType.Insert,
translate: { x: 300 }
})
.transition({
type: TransitionType.Delete,
translate: { x: -300 }
})
}, (diary: DiaryInfo) => diary.id)
}
.animation({ duration: 300, curve: Curve.EaseOut })
六、条件渲染与 ForEach 配合
if (this.diaries.length === 0) {
// 空状态
Column() {
Text('暂无日记')
}
} else {
List() {
ForEach(this.diaries, (diary: DiaryInfo) => {
ListItem() {
this.DiaryCard(diary)
}
}, (diary: DiaryInfo) => diary.id)
}
}
七、列表项的事件处理
7.1 点击事件
ForEach(this.diaries, (diary: DiaryInfo) => {
ListItem() {
this.DiaryCard(diary)
}
.onClick(() => {
this.goToDetail(diary.id)
})
}, (diary: DiaryInfo) => diary.id)
7.2 长按事件
ForEach(this.diaries, (diary: DiaryInfo) => {
ListItem() {
this.DiaryCard(diary)
}
.onClick(() => {
this.goToDetail(diary.id)
})
.gesture(
LongPressGesture()
.onAction(() => {
this.showDeleteConfirm(diary.id)
})
)
}, (diary: DiaryInfo) => diary.id)
7.3 滑动删除
ForEach(this.diaries, (diary: DiaryInfo) => {
ListItem() {
this.DiaryCard(diary)
}
.swipeAction({
end: {
builder: () => {
Button('删除')
.backgroundColor('#FF3B30')
.onClick(() => {
this.deleteDiary(diary.id)
})
}
}
})
}, (diary: DiaryInfo) => diary.id)
八、总结
列表渲染的核心要点:
- 键值必填:始终提供唯一的键值生成器,确保 Diff 算法高效工作
- 性能选择:少量数据用
ForEach,大量数据用LazyForEach - 嵌套渲染:支持 ForEach 嵌套实现分组列表
- 事件绑定:在 ListItem 上绑定点击、长按、滑动等交互
- 动画支持:通过
transition实现列表项的增删动画 - 条件配合:与
if-else配合处理空状态
ForEach 是 ArkUI 中最常用的渲染指令,理解其原理和最佳实践对开发高质量列表页面至关重要。
