AtomGit Flutter鸿蒙客户端:仓库详情页
本文介绍了Flutter实现的仓库详情页设计与实现要点: 路由参数:通过命名路由传递owner和name参数,使用ModalRoute提取参数 数据加载: RepoDetailProvider在创建时自动加载数据 对owner和name进行URI编码处理特殊字符 README采用静默加载策略,Base64解码后渲染 页面结构: 使用ChangeNotifierProvider管理状态 Statel
·

路由参数
仓库详情页通过命名路由 /repo 进入,接收 owner 和 name 参数:
// 导航到详情页
Navigator.pushNamed(context, '/repo',
arguments: {'owner': 'atomgit', 'name': 'flutter-ohos'});
// 详情页提取参数
final args =
ModalRoute.of(context)!.settings.arguments as Map<String, dynamic>;
final owner = args['owner'] as String;
final name = args['name'] as String;
RepoDetailProvider
Provider 在创建时即开始加载数据:
class RepoDetailProvider extends ChangeNotifier {
final AtomGitApiClient _apiClient;
Repository? _repository;
String? _readme;
bool _isLoading = false;
String? _error;
Future<void> load(String owner, String name) async {
_isLoading = true;
_error = null;
notifyListeners();
try {
final encodedOwner = Uri.encodeComponent(owner);
final encodedName = Uri.encodeComponent(name);
final response = await _apiClient.get(
'/repos/$encodedOwner/$encodedName',
);
final data = parseMap(response.data);
if (data != null) {
_repository = Repository.fromJson(data);
}
_readme = await _loadReadme(encodedOwner, encodedName,
_repository?.defaultBranch ?? 'main');
} on ApiException catch (e) {
_error = e.message;
} catch (e) {
_error = '加载失败: $e';
} finally {
_isLoading = false;
notifyListeners();
}
}
}
关键细节:owner 和 name 都经过 Uri.encodeComponent 编码,处理含特殊字符的仓库路径。
README 加载
README 加载采用静默失败策略 —— 没有 README 不报错,只是不展示:
Future<String?> _loadReadme(
String owner, String repo, String branch) async {
try {
final response = await _apiClient.get(
'/repos/$owner/$repo/readme',
queryParams: {'ref': branch},
);
final data = parseMap(response.data);
if (data != null && data['content'] is String) {
final content = data['content'] as String;
return utf8.decode(base64.decode(content));
}
} on ApiException {
// README 不存在是正常的,不报错
} catch (_) {}
return null;
}
API 返回的 README 内容是 Base64 编码的,解码后用 MarkdownViewer 渲染。
页面结构
RepoDetailScreen 是 StatelessWidget,通过 ChangeNotifierProvider 注入 Provider:
class RepoDetailScreen extends StatelessWidget {
Widget build(BuildContext context) {
final args =
ModalRoute.of(context)!.settings.arguments as Map<String, dynamic>;
final owner = args['owner'] as String;
final name = args['name'] as String;
return ChangeNotifierProvider(
create: (_) => RepoDetailProvider(context.read<AtomGitApiClient>())
..load(owner, name),
child: _RepoDetailBody(owner: owner, name: name),
);
}
}
自定义 Tab 栏
不使用 Flutter 的 TabBar/TabBarView,而是自定义 Row 按钮实现四个标签切换:
enum _DetailTab { code, issues, pulls, readme }
class _RepoDetailBodyState extends State<_RepoDetailBody> {
_DetailTab _currentTab = _DetailTab.readme;
Widget _buildTabBar() {
return Material(
elevation: 1,
child: Padding(
padding: const EdgeInsets.symmetric(horizontal: 16, vertical: 8),
child: Row(
children: [
_TabButton(
label: '代码',
isSelected: _currentTab == _DetailTab.code,
onTap: () {
Navigator.pushNamed(context, '/repo/code', arguments: {
'owner': widget.owner,
'name': widget.name,
'branch': provider.repository?.defaultBranch ?? 'main',
});
},
),
_TabButton(
label: 'Issues',
isSelected: _currentTab == _DetailTab.issues,
onTap: () {
Navigator.pushNamed(context, '/repo/issues', arguments: {
'owner': widget.owner,
'name': widget.name,
'type': 'issue',
});
},
),
_TabButton(
label: 'PRs',
isSelected: _currentTab == _DetailTab.pulls,
onTap: () {
Navigator.pushNamed(context, '/repo/pulls', arguments: {
'owner': widget.owner,
'name': widget.name,
'type': 'pr',
});
},
),
_TabButton(
label: 'README',
isSelected: _currentTab == _DetailTab.readme,
onTap: () => setState(() => _currentTab = _DetailTab.readme),
),
],
),
),
);
}
}
每个按钮的选中态通过底部蓝色指示条实现:
class _TabButton extends StatelessWidget {
final String label;
final bool isSelected;
final VoidCallback onTap;
Widget build(BuildContext context) {
return Expanded(
child: GestureDetector(
onTap: onTap,
child: Column(
children: [
Text(label, style: TextStyle(
color: isSelected
? Theme.of(context).colorScheme.primary
: null,
fontWeight: isSelected ? FontWeight.w600 : null,
)),
if (isSelected)
Container(
height: 2,
margin: const EdgeInsets.only(top: 4),
color: Theme.of(context).colorScheme.primary,
),
],
),
),
);
}
}
头部信息区
仓库名、描述、统计数据以卡片形式展示:
Widget _buildRepoHeader(Repository repo) {
return Card(
margin: const EdgeInsets.all(16),
child: Padding(
padding: const EdgeInsets.all(16),
child: Column(
crossAxisAlignment: CrossAxisAlignment.start,
children: [
Row(children: [
Icon(repo.isPrivate ? Icons.lock_outline : Icons.book_outlined,
size: 20),
const SizedBox(width: 8),
Expanded(child: Text(repo.fullName,
style: Theme.of(context).textTheme.titleMedium)),
]),
if (repo.description != null) ...[
const SizedBox(height: 8),
Text(repo.description!),
],
const SizedBox(height: 12),
Row(children: [
_StatItem(Icons.star_border, '${repo.stargazersCount}'),
_StatItem(Icons.call_split, '${repo.forksCount}'),
_StatItem(Icons.remove_red_eye_outlined, '${repo.watchersCount}'),
_StatItem(Icons.error_outline, '${repo.openIssuesCount}'),
]),
],
),
),
);
}
README 渲染
Widget _buildReadme(RepoDetailProvider provider) {
if (provider.readme == null || provider.readme!.isEmpty) {
return const Center(child: Text('暂无 README'));
}
return SingleChildScrollView(
padding: const EdgeInsets.all(16),
child: MarkdownViewer(markdown: provider.readme!),
);
}
状态处理
三种状态的完整处理:
Widget _buildBody(RepoDetailProvider provider) {
if (provider.error != null && provider.repository == null) {
return ErrorRetryWidget(
message: provider.error!,
onRetry: () => provider.load(widget.owner, widget.name),
);
}
if (provider.repository == null) {
return const LoadingIndicator(message: '加载仓库信息...');
}
return Column(children: [
_buildTabBar(),
Expanded(child: _buildReadme(provider)),
]);
}
错误时展示可重试的错误页面,加载中展示 LoadingIndicator,成功后展示完整内容。
