HarmonyOS 6 悬浮导航 + 沉浸光感:打造鸿蒙智能体驱动的沉浸式智能家居控制中枢
在万物互联的时代,智能家居已经成为现代生活的重要组成部分。然而,传统的智能家居控制方式往往存在诸多不便:需要打开特定的APP、在不同设备间频繁切换、无法感知用户的实时需求。当双手沾满面粉时想调节厨房灯光亮度,当抱着婴儿时想关闭卧室窗帘——这些场景下,传统的触控操作显得笨拙而低效。HarmonyOS 6(API 23)带来的悬浮导航(Floating Navigation)和沉浸光感(Immersi

每日一句正能量
少与人争,才能宠辱不惊,闲看庭前花开花落,少与己争,方可去留无意,漫随天外云卷云舒。
不与人争辩对错高下,外界的毁誉就伤不到你;不与自己较劲、不苛责过去的决定,内心的波动就会平息。
一、前言:当AI管家常驻屏幕边缘
在万物互联的时代,智能家居已经成为现代生活的重要组成部分。然而,传统的智能家居控制方式往往存在诸多不便:需要打开特定的APP、在不同设备间频繁切换、无法感知用户的实时需求。当双手沾满面粉时想调节厨房灯光亮度,当抱着婴儿时想关闭卧室窗帘——这些场景下,传统的触控操作显得笨拙而低效。
HarmonyOS 6(API 23)带来的悬浮导航(Floating Navigation)和沉浸光感(Immersive Lighting)能力,让我们有机会打造一个常驻屏幕边缘的AI智能管家——它像一位贴心的家庭管家,在你需要时随时唤出,通过语音、手势甚至环境感知自动执行控制;它通过光效反馈家居状态,让你无需看屏幕就能感知家中一切。
核心创新点:
- 🏠 全屋设备悬浮掌控:悬浮窗常驻显示核心家居状态,支持跨场景快速控制
- 💡 环境状态光感:通过设备边框光效颜色变化,反映家中环境状态(温度/安防/能耗)
- 🤖 情境感知智能体:自动识别用户场景(回家/离家/睡眠/观影),主动推荐控制方案
- 🎙️ 多模态交互:语音控制 + 手势操作 + 环境感知,解放双手
二、应用场景设计
2.1 场景一:烹饪助手模式
用户在厨房做饭,双手沾满油污。通过语音"把厨房灯调亮一点",悬浮窗AI智能体识别指令,自动调节灯光亮度,同时边框泛起温暖的橙色光效,表示"烹饪模式"已激活。
2.2 场景二:安防状态感知
深夜家中门窗传感器被触发,设备四周边框立即泛起红色脉冲光效,悬浮窗自动展开显示安防摄像头画面和异常位置,同时智能体分析是否为误报(宠物/风吹)。
2.3 场景三:能耗优化建议
AI智能体持续学习用户用电习惯,在悬浮窗中推送"检测到您每天18:00-20:00空调设定温度过低,建议调整为26℃可节省15%电费",边框泛起绿色光效表示"节能建议"。
三、技术架构
┌─────────────────────────────────────────────────────────────┐
│ HarmonyOS Smart Home Control Center Agent │
├─────────────┬─────────────┬─────────────┬───────────────────┤
│ 悬浮窗UI │ 沉浸光感 │ 智能体引擎 │ 设备接入模块 │
│ FloatUI │ Lighting │ AI Engine │ DeviceConnector │
├─────────────┴─────────────┴─────────────┴───────────────────┤
│ 情境感知层(Context Aware) │
│ 位置感知 │ 时间分析 │ 环境检测 │ 用户习惯 │ 语音理解 │
├─────────────────────────────────────────────────────────────┤
│ HarmonyOS 6 (API 23) 系统服务层 │
│ 悬浮导航 │ 光感服务 │ 智能体框架 │ 分布式设备 │ 语音服务 │
└─────────────────────────────────────────────────────────────┘
四、核心代码实现
4.1 家居设备上下文感知引擎(HomeContextEngine)
这是整个系统的"感官",通过分布式设备服务实时接入全屋智能设备,分析家居环境状态。
// engine/HomeContextEngine.ets
import { deviceManager } from '@kit.DistributedServiceKit';
import { sensor } from '@kit.SensorServiceKit';
import { BusinessError } from '@kit.BasicServicesKit';
export interface HomeContext {
location: UserLocation; // 用户当前位置
timeContext: TimeContext; // 时间上下文
environment: EnvironmentState; // 环境状态
activeDevices: SmartDevice[]; // 活跃设备列表
securityStatus: SecurityLevel; // 安防级别
energyStatus: EnergyStatus; // 能耗状态
scenePrediction: PredictedScene; // 场景预测
}
export enum UserLocation {
HOME = 'home',
LIVING_ROOM = 'living_room',
BEDROOM = 'bedroom',
KITCHEN = 'kitchen',
BATHROOM = 'bathroom',
AWAY = 'away'
}
export interface TimeContext {
hour: number;
isWeekend: boolean;
isHoliday: boolean;
season: 'spring' | 'summer' | 'autumn' | 'winter';
dayPhase: 'dawn' | 'morning' | 'afternoon' | 'evening' | 'night' | 'midnight';
}
export interface EnvironmentState {
temperature: number; // 温度
humidity: number; // 湿度
illuminance: number; // 光照度
airQuality: number; // 空气质量指数
noiseLevel: number; // 噪音分贝
}
export enum SecurityLevel {
SAFE = 'safe', // 安全:绿色
CAUTION = 'caution', // 注意:黄色
ALERT = 'alert', // 警戒:橙色
EMERGENCY = 'emergency' // 紧急:红色
}
export interface EnergyStatus {
currentPower: number; // 当前功率(W)
dailyUsage: number; // 今日用电量(kWh)
monthlyUsage: number; // 本月用电量(kWh)
estimatedCost: number; // 预估电费
efficiency: number; // 能效等级 0-100
}
export interface PredictedScene {
scene: string; // 预测场景
confidence: number; // 置信度
triggerTime: number; // 预计触发时间
suggestedActions: ActionSuggestion[];
}
export interface ActionSuggestion {
deviceId: string;
action: string;
value: any;
reason: string;
}
export interface SmartDevice {
id: string;
name: string;
type: DeviceType;
location: string;
status: DeviceStatus;
isOnline: boolean;
lastActive: number;
}
export enum DeviceType {
LIGHT = 'light',
AC = 'air_conditioner',
CURTAIN = 'curtain',
CAMERA = 'camera',
LOCK = 'smart_lock',
SENSOR = 'sensor',
SWITCH = 'switch',
SPEAKER = 'speaker'
}
export interface DeviceStatus {
power: 'on' | 'off';
brightness?: number;
temperature?: number;
mode?: string;
locked?: boolean;
}
export class HomeContextEngine {
private deviceManager: deviceManager.DeviceManager | null = null;
private sensorManager: sensor.SensorManager | null = null;
private contextCallbacks: Array<(context: HomeContext) => void> = [];
private currentContext: HomeContext | null = null;
private updateInterval: number = 0;
private deviceCache: Map<string, SmartDevice> = new Map();
/**
* 初始化家居上下文感知
* 亮点:通过分布式设备管理接入全屋设备,支持跨设备协同
*/
async init(): Promise<void> {
try {
// 初始化设备管理器
this.deviceManager = await deviceManager.createDeviceManager({
bundleName: getContext(this).applicationInfo.name
});
// 注册设备状态变更监听
this.deviceManager.on('deviceStateChange', (event) => {
this.handleDeviceChange(event);
});
// 初始化传感器管理器
this.sensorManager = sensor.getSensorManager();
// 启动定时刷新(每10秒)
this.updateInterval = setInterval(() => this.refreshContext(), 10000);
// 首次上下文构建
await this.refreshContext();
console.info('[HomeContext] 家居上下文感知引擎初始化完成');
} catch (err) {
console.error(`[HomeContext] 初始化失败: ${JSON.stringify(err)}`);
}
}
/**
* 刷新家居上下文
*/
private async refreshContext(): Promise<void> {
try {
// 获取用户位置
const location = await this.detectUserLocation();
// 获取时间上下文
const timeContext = this.buildTimeContext();
// 获取环境状态
const environment = await this.readEnvironmentSensors();
// 获取设备状态
const devices = await this.queryAllDevices();
// 分析安防状态
const security = this.analyzeSecurityStatus(devices);
// 分析能耗状态
const energy = this.calculateEnergyStatus(devices);
// 预测场景
const prediction = this.predictScene(location, timeContext, devices);
const context: HomeContext = {
location,
timeContext,
environment,
activeDevices: devices.filter(d => d.status.power === 'on'),
securityStatus: security,
energyStatus: energy,
scenePrediction: prediction
};
this.currentContext = context;
// 通知订阅者
this.contextCallbacks.forEach(cb => cb(context));
} catch (err) {
console.error(`[HomeContext] 刷新失败: ${JSON.stringify(err)}`);
}
}
/**
* 检测用户位置
* 策略:多源融合(GPS + WiFi指纹 + 设备使用习惯)
*/
private async detectUserLocation(): Promise<<UserLocation> {
// 简化实现,实际应融合多源数据
const hour = new Date().getHours();
if (hour >= 7 && hour <= 9) return UserLocation.KITCHEN;
if (hour >= 19 && hour <= 23) return UserLocation.LIVING_ROOM;
if (hour >= 23 || hour <= 7) return UserLocation.BEDROOM;
return UserLocation.HOME;
}
/**
* 构建时间上下文
*/
private buildTimeContext(): TimeContext {
const now = new Date();
const hour = now.getHours();
let dayPhase: TimeContext['dayPhase'] = 'morning';
if (hour >= 5 && hour < 8) dayPhase = 'dawn';
else if (hour >= 8 && hour < 12) dayPhase = 'morning';
else if (hour >= 12 && hour < 14) dayPhase = 'afternoon';
else if (hour >= 14 && hour < 18) dayPhase = 'afternoon';
else if (hour >= 18 && hour < 22) dayPhase = 'evening';
else if (hour >= 22 && hour < 24) dayPhase = 'night';
else dayPhase = 'midnight';
const month = now.getMonth();
let season: TimeContext['season'] = 'spring';
if (month >= 3 && month <= 5) season = 'spring';
else if (month >= 6 && month <= 8) season = 'summer';
else if (month >= 9 && month <= 11) season = 'autumn';
else season = 'winter';
return {
hour,
isWeekend: now.getDay() === 0 || now.getDay() === 6,
isHoliday: false, // 实际应查询节假日API
season,
dayPhase
};
}
/**
* 读取环境传感器
*/
private async readEnvironmentSensors(): Promise<<EnvironmentState> {
try {
// 读取温度湿度传感器
const thSensor = await this.sensorManager?.getSingleSensor(
sensor.SensorId.SENSOR_TYPE_AMBIENT_TEMPERATURE
);
// 读取光照传感器
const lightSensor = await this.sensorManager?.getSingleSensor(
sensor.SensorId.SENSOR_TYPE_AMBIENT_LIGHT
);
return {
temperature: thSensor?.temperature || 24,
humidity: thSensor?.humidity || 50,
illuminance: lightSensor?.intensity || 300,
airQuality: 85, // 模拟数据
noiseLevel: 45 // 模拟数据
};
} catch (err) {
// 传感器不可用,返回默认值
return {
temperature: 24,
humidity: 50,
illuminance: 300,
airQuality: 85,
noiseLevel: 45
};
}
}
/**
* 查询所有设备状态
*/
private async queryAllDevices(): Promise<<SmartDevice[]> {
if (!this.deviceManager) return [];
try {
const deviceList = await this.deviceManager.getTrustedDeviceListSync();
const devices: SmartDevice[] = [];
for (const deviceInfo of deviceList) {
const device = await this.queryDeviceStatus(deviceInfo.deviceId);
if (device) {
this.deviceCache.set(device.id, device);
devices.push(device);
}
}
return devices;
} catch (err) {
// 返回缓存数据
return Array.from(this.deviceCache.values());
}
}
/**
* 查询单个设备状态
*/
private async queryDeviceStatus(deviceId: string): Promise<<SmartDevice | null> {
// 实际应通过分布式通信查询设备状态
// 简化实现
const mockDevices: Record<string, SmartDevice> = {
'light_001': {
id: 'light_001',
name: '客厅主灯',
type: DeviceType.LIGHT,
location: 'living_room',
status: { power: 'on', brightness: 80 },
isOnline: true,
lastActive: Date.now()
},
'ac_001': {
id: 'ac_001',
name: '主卧空调',
type: DeviceType.AC,
location: 'bedroom',
status: { power: 'on', temperature: 26, mode: 'cool' },
isOnline: true,
lastActive: Date.now()
},
'camera_001': {
id: 'camera_001',
name: '门口摄像头',
type: DeviceType.CAMERA,
location: 'entrance',
status: { power: 'on' },
isOnline: true,
lastActive: Date.now()
}
};
return mockDevices[deviceId] || null;
}
/**
* 分析安防状态
*/
private analyzeSecurityStatus(devices: SmartDevice[]): SecurityLevel {
const sensors = devices.filter(d => d.type === DeviceType.SENSOR);
// 检查门窗传感器
const doorSensors = sensors.filter(s => s.location.includes('door') || s.location.includes('window'));
const triggeredSensors = doorSensors.filter(s => s.status.power === 'on' && this.isSensorTriggered(s));
if (triggeredSensors.length > 0) {
const hour = new Date().getHours();
// 深夜触发更紧急
if (hour >= 23 || hour <= 6) return SecurityLevel.EMERGENCY;
return SecurityLevel.ALERT;
}
// 检查摄像头异常
const cameras = devices.filter(d => d.type === DeviceType.CAMERA);
const offlineCameras = cameras.filter(c => !c.isOnline);
if (offlineCameras.length > 0) return SecurityLevel.CAUTION;
return SecurityLevel.SAFE;
}
private isSensorTriggered(sensor: SmartDevice): boolean {
// 简化:假设传感器有triggered字段
return (sensor.status as any).triggered === true;
}
/**
* 计算能耗状态
*/
private calculateEnergyStatus(devices: SmartDevice[]): EnergyStatus {
const activeDevices = devices.filter(d => d.status.power === 'on');
// 估算功率
const powerMap: Record<string, number> = {
'light': 15,
'air_conditioner': 1500,
'curtain': 50,
'camera': 10,
'smart_lock': 5,
'speaker': 20
};
const currentPower = activeDevices.reduce((sum, d) => {
return sum + (powerMap[d.type] || 50);
}, 0);
// 模拟日用电量和月用电量
const dailyUsage = currentPower * 8 / 1000; // 假设8小时
const monthlyUsage = dailyUsage * 30;
return {
currentPower,
dailyUsage,
monthlyUsage,
estimatedCost: monthlyUsage * 0.6, // 假设0.6元/度
efficiency: Math.max(100 - (currentPower / 3000) * 100, 0)
};
}
/**
* 场景预测
* 基于时间、位置、历史习惯预测用户下一步行为
*/
private predictScene(location: UserLocation, time: TimeContext, devices: SmartDevice[]): PredictedScene {
const suggestions: ActionSuggestion[] = [];
let scene = 'normal';
let confidence = 0.5;
// 回家场景
if (location === UserLocation.HOME && time.hour >= 18 && time.dayPhase === 'evening') {
scene = 'home_return';
confidence = 0.85;
suggestions.push(
{ deviceId: 'light_001', action: 'turn_on', value: { brightness: 80 }, reason: '傍晚回家,自动开灯' },
{ deviceId: 'ac_001', action: 'set_temperature', value: 26, reason: '提前调节室温' }
);
}
// 睡眠场景
if (location === UserLocation.BEDROOM && time.hour >= 22) {
scene = 'sleep';
confidence = 0.9;
suggestions.push(
{ deviceId: 'light_001', action: 'turn_off', value: null, reason: '准备入睡,关闭灯光' },
{ deviceId: 'ac_001', action: 'set_temperature', value: 27, reason: '睡眠模式,节能舒适' }
);
}
// 观影场景
if (location === UserLocation.LIVING_ROOM && time.hour >= 20 && time.dayPhase === 'evening') {
scene = 'movie';
confidence = 0.6;
suggestions.push(
{ deviceId: 'light_001', action: 'set_brightness', value: 20, reason: '观影模式,降低亮度' },
{ deviceId: 'curtain_001', action: 'close', value: null, reason: '关闭窗帘,提升观影体验' }
);
}
return {
scene,
confidence,
triggerTime: Date.now() + 300000, // 5分钟后
suggestedActions: suggestions
};
}
/**
* 执行设备控制
*/
async controlDevice(deviceId: string, action: string, value?: any): Promise<<boolean> {
try {
// 实际应通过分布式通信发送控制指令
console.info(`[HomeContext] 控制设备: ${deviceId}, 动作: ${action}, 值: ${value}`);
// 更新本地缓存
const device = this.deviceCache.get(deviceId);
if (device) {
if (action === 'turn_on') device.status.power = 'on';
if (action === 'turn_off') device.status.power = 'off';
if (action === 'set_brightness') device.status.brightness = value;
if (action === 'set_temperature') device.status.temperature = value;
}
return true;
} catch (err) {
console.error(`[HomeContext] 控制失败: ${JSON.stringify(err)}`);
return false;
}
}
onContextChange(callback: (context: HomeContext) => void): void {
this.contextCallbacks.push(callback);
}
getCurrentContext(): HomeContext | null {
return this.currentContext;
}
private handleDeviceChange(event: deviceManager.DeviceStateChangeEvent): void {
// 设备状态变更时刷新上下文
this.refreshContext();
}
destroy(): void {
clearInterval(this.updateInterval);
this.deviceManager?.off('deviceStateChange');
}
}
4.2 沉浸光感家居状态反馈(HomeLightingController)
光效是家居状态的"环境化延伸",让用户无需看屏幕就能感知家中状态。
// lighting/HomeLightingController.ets
import { lighting } from '@kit.ArkUI';
import { SecurityLevel, EnergyStatus, EnvironmentState, TimeContext } from '../engine/HomeContextEngine';
export class HomeLightingController {
private currentMode: string = 'normal';
private isNightMode: boolean = false;
/**
* 初始化家居光感
* 设计哲学:光效应成为家居状态的"环境氛围"
*/
async init(): Promise<void> {
if (!lighting.isImmersiveLightSupported()) {
console.warn('[HomeLight] 设备不支持沉浸光感');
return;
}
// 初始状态:柔和白色
await this.setLightEffect({
type: 'solid',
position: 'bottom_edge',
color: '#E0E0E0',
brightness: 20,
duration: 0
});
console.info('[HomeLight] 家居光感初始化完成');
}
/**
* 根据家居状态更新光效
*/
async updateByContext(context: {
security: SecurityLevel;
energy: EnergyStatus;
environment: EnvironmentState;
time: TimeContext;
location: string;
}): Promise<void> {
// 优先级:安防 > 能耗 > 环境舒适 > 时间氛围
// 安防状态最高优先级
if (context.security !== SecurityLevel.SAFE) {
await this.setSecurityLighting(context.security);
return;
}
// 能耗异常
if (context.energy.efficiency < 50) {
await this.setEnergyAlert(context.energy);
return;
}
// 环境不适
if (context.environment.temperature > 30 || context.environment.temperature < 16) {
await this.setEnvironmentAlert(context.environment);
return;
}
// 正常状态:根据时间和位置营造氛围
await this.setAmbientLighting(context.time, context.location);
}
/**
* 安防状态光效
*/
private async setSecurityLighting(level: SecurityLevel): Promise<void> {
const effects: Record<<SecurityLevel, lighting.LightEffect> = {
[SecurityLevel.SAFE]: {
type: 'solid',
position: 'bottom_edge',
color: '#00E676',
brightness: 20,
duration: 0
},
[SecurityLevel.CAUTION]: {
type: 'breathing',
position: 'bottom_edge',
color: '#FFD600',
brightness: 40,
duration: 0,
frequency: 2000
},
[SecurityLevel.ALERT]: {
type: 'flashing',
position: 'all_edges',
color: '#FF9100',
brightness: 60,
duration: 0,
flashCount: -1,
frequency: 1000
},
[SecurityLevel.EMERGENCY]: {
type: 'flashing',
position: 'all_edges',
color: '#FF1744',
brightness: 80,
duration: 0,
flashCount: -1,
frequency: 500
}
};
await lighting.setImmersiveLight(effects[level]);
console.info(`[HomeLight] 安防光效: ${level}`);
}
/**
* 能耗告警光效
*/
private async setEnergyAlert(energy: EnergyStatus): Promise<void> {
await lighting.setImmersiveLight({
type: 'wave',
position: 'all_edges',
color: '#FF9100',
brightness: 50,
duration: 0,
direction: 'clockwise',
speed: 'slow'
});
}
/**
* 环境异常光效
*/
private async setEnvironmentAlert(env: EnvironmentState): Promise<void> {
const isHot = env.temperature > 30;
await lighting.setImmersiveLight({
type: 'breathing',
position: 'all_edges',
color: isHot ? '#FF5722' : '#2196F3', // 热=红橙,冷=蓝
brightness: 45,
duration: 0,
frequency: 2500
});
}
/**
* 氛围光效
* 根据时间和位置营造舒适氛围
*/
private async setAmbientLighting(time: TimeContext, location: string): Promise<void> {
const isNight = time.dayPhase === 'night' || time.dayPhase === 'midnight';
this.isNightMode = isNight;
// 深夜模式:极暗,不影响睡眠
if (time.dayPhase === 'midnight') {
await lighting.setImmersiveLight({
type: 'solid',
position: 'bottom_edge',
color: '#1A237E', // 深蓝
brightness: 5,
duration: 0
});
return;
}
// 根据位置设置不同氛围
const locationColors: Record<string, string> = {
'living_room': isNight ? '#FF6F00' : '#FFE0B2', // 客厅:暖橙
'bedroom': isNight ? '#4A148C' : '#E1BEE7', // 卧室:柔和紫
'kitchen': '#FFF3E0', // 厨房:暖白
'bathroom': '#E0F7FA' // 浴室:清新蓝
};
const color = locationColors[location] || '#E0E0E0';
const brightness = isNight ? 15 : 25;
await lighting.setImmersiveLight({
type: 'solid',
position: 'bottom_edge',
color: color,
brightness: brightness,
duration: 0
});
}
/**
* 执行控制时的反馈光效
*/
async controlFeedback(success: boolean): Promise<void> {
await lighting.setImmersiveLight({
type: 'flashing',
position: 'bottom_edge',
color: success ? '#00E676' : '#FF1744',
brightness: 40,
duration: 500,
flashCount: 1
});
}
/**
* 场景切换动画
*/
async sceneTransition(sceneName: string): Promise<void> {
const sceneColors: Record<string, string> = {
'home_return': '#FF9800', // 回家:温暖橙
'sleep': '#3F51B5', // 睡眠:静谧蓝
'movie': '#212121', // 观影:深黑
'party': '#E91E63', // 聚会:活力粉
'reading': '#FFEB3B' // 阅读:明亮黄
};
const color = sceneColors[sceneName] || '#E0E0E0';
// 渐变过渡
await lighting.setImmersiveLight({
type: 'solid',
position: 'all_edges',
color: color,
brightness: 30,
duration: 1000
});
await new Promise(resolve => setTimeout(resolve, 1000));
// 恢复氛围
// 实际应恢复之前的状态...
}
async reset(): Promise<void> {
await lighting.resetImmersiveLight();
}
}
4.3 家居智能体引擎(HomeAgentEngine)
这是系统的"智能管家大脑",负责理解用户意图、生成控制策略、提供生活建议。
// agent/HomeAgentEngine.ets
import { ai } from '@kit.AiKit';
import { HomeContext, SmartDevice, ActionSuggestion, UserLocation, TimeContext } from '../engine/HomeContextEngine';
export interface HomeResponse {
type: 'control' | 'query' | 'suggestion' | 'alert';
message: string;
actions?: ActionSuggestion[];
data?: any;
confidence: number;
}
export class HomeAgentEngine {
private agent: ai.AgentSession | null = null;
private userHabits: Map<string, any> = new Map(); // 用户习惯学习
private commandHistory: string[] = []; // 指令历史
/**
* 初始化家居智能体
* 加载家居控制知识库
*/
async init(): Promise<void> {
const model = await ai.createModel({
modelId: 'harmonyos-home-agent-v1',
type: ai.ModelType.LOCAL,
capabilities: ['nlp', 'intent_recognition', 'home_automation']
});
this.agent = await ai.createAgentSession({
model: model,
systemPrompt: `你是一位专业的智能家居管家,精通HarmonyOS全屋智能系统。
请基于用户指令和当前家居状态,提供:
1. 精确的设备控制指令
2. 场景化的智能建议
3. 能耗优化方案
4. 安防状态提醒
控制指令格式:
- 开/关:{ "deviceId": "xxx", "action": "turn_on/off" }
- 调节:{ "deviceId": "xxx", "action": "set_xxx", "value": xxx }
回答要求:
- 用自然语言解释执行的操作
- 提供执行原因
- 给出相关建议`
});
console.info('[HomeAgent] 家居智能体初始化完成');
}
/**
* 处理自然语言指令
*/
async processCommand(command: string, context: HomeContext): Promise<<HomeResponse> {
if (!this.agent) return { type: 'query', message: '智能体未初始化', confidence: 0 };
this.commandHistory.push(command);
// 意图识别
const intent = await this.recognizeIntent(command);
switch (intent.type) {
case 'control':
return await this.handleControlIntent(intent, context);
case 'query':
return await this.handleQueryIntent(intent, context);
case 'scene':
return await this.handleSceneIntent(intent, context);
default:
return await this.handleGeneralQuery(command, context);
}
}
/**
* 识别用户意图
*/
private async recognizeIntent(command: string): Promise<<{ type: string; entities: any }> {
const prompt = `分析用户指令的意图和实体:
指令:"${command}"
请输出JSON格式:
{
"type": "control|query|scene|general",
"entities": {
"device": "设备名称或类型",
"action": "动作",
"value": "数值",
"location": "位置"
}
}`;
const result = await this.agent!.invoke({
input: { question: prompt },
options: { maxTokens: 256, temperature: 0.1 }
});
return JSON.parse(result.data?.intent || '{"type":"general","entities":{}}');
}
/**
* 处理控制意图
*/
private async handleControlIntent(intent: any, context: HomeContext): Promise<<HomeResponse> {
const { device, action, value, location } = intent.entities;
// 查找目标设备
let targetDevice: SmartDevice | undefined;
if (device) {
targetDevice = context.activeDevices.find(d =>
d.name.includes(device) || d.type === device
);
}
if (location && !targetDevice) {
targetDevice = context.activeDevices.find(d => d.location === location);
}
if (!targetDevice) {
return {
type: 'query',
message: `未找到${device || location}对应的设备,请检查设备名称`,
confidence: 0.3
};
}
// 生成控制动作
const controlAction: ActionSuggestion = {
deviceId: targetDevice.id,
action: this.mapAction(action),
value: this.parseValue(value, action),
reason: `根据您的指令"${intent.original}"执行`
};
return {
type: 'control',
message: `已为您${action}${targetDevice.name}${value ? '到' + value : ''}`,
actions: [controlAction],
confidence: 0.9
};
}
/**
* 处理查询意图
*/
private async handleQueryIntent(intent: any, context: HomeContext): Promise<<HomeResponse> {
const { device, location } = intent.entities;
if (intent.entities.queryType === 'temperature') {
return {
type: 'query',
message: `当前室内温度${context.environment.temperature}℃,湿度${context.environment.humidity}%,${context.environment.temperature > 28 ? '建议开启空调' : '体感舒适'}`,
data: context.environment,
confidence: 0.95
};
}
if (intent.entities.queryType === 'security') {
const status = context.securityStatus === 'safe' ? '安全' :
context.securityStatus === 'caution' ? '需注意' :
context.securityStatus === 'alert' ? '警戒中' : '紧急';
return {
type: 'query',
message: `家中安防状态:${status}。${context.securityStatus !== 'safe' ? '请立即查看详情' : '一切正常'}`,
data: { security: context.securityStatus },
confidence: 0.95
};
}
if (intent.entities.queryType === 'energy') {
return {
type: 'query',
message: `今日用电${context.energyStatus.dailyUsage.toFixed(1)}度,预估电费${context.energyStatus.estimatedCost.toFixed(1)}元。能效等级${context.energyStatus.efficiency > 80 ? '优秀' : context.energyStatus.efficiency > 60 ? '良好' : '需优化'}`,
data: context.energyStatus,
confidence: 0.9
};
}
return {
type: 'query',
message: '我可以帮您查询温度、安防、能耗等状态,请问您想了解什么?',
confidence: 0.5
};
}
/**
* 处理场景意图
*/
private async handleSceneIntent(intent: any, context: HomeContext): Promise<<HomeResponse> {
const sceneName = intent.entities.scene;
const sceneActions: Record<string, ActionSuggestion[]> = {
'home': [
{ deviceId: 'light_001', action: 'turn_on', value: { brightness: 80 }, reason: '回家模式:欢迎回家' },
{ deviceId: 'ac_001', action: 'set_temperature', value: 26, reason: '调节舒适温度' }
],
'sleep': [
{ deviceId: 'light_001', action: 'turn_off', value: null, reason: '睡眠模式:晚安' },
{ deviceId: 'ac_001', action: 'set_temperature', value: 27, reason: '睡眠温度' },
{ deviceId: 'curtain_001', action: 'close', value: null, reason: '关闭窗帘' }
],
'movie': [
{ deviceId: 'light_001', action: 'set_brightness', value: 20, reason: '观影模式' },
{ deviceId: 'curtain_001', action: 'close', value: null, reason: '关闭窗帘' }
],
'away': [
{ deviceId: 'light_001', action: 'turn_off', value: null, reason: '离家模式:节能' },
{ deviceId: 'ac_001', action: 'turn_off', value: null, reason: '关闭空调' },
{ deviceId: 'camera_001', action: 'turn_on', value: null, reason: '开启安防' }
]
};
const actions = sceneActions[sceneName] || [];
return {
type: 'control',
message: `已切换到${sceneName}模式,${actions.length}个设备已调整`,
actions,
confidence: 0.95
};
}
/**
* 处理一般查询
*/
private async handleGeneralQuery(command: string, context: HomeContext): Promise<<HomeResponse> {
const prompt = `用户问题:${command}
当前家居状态:
- 位置:${context.location}
- 时间:${context.timeContext.dayPhase}
- 温度:${context.environment.temperature}℃
- 安防:${context.securityStatus}
- 能耗:${context.energyStatus.dailyUsage}度/天
请给出有帮助的回答。`;
const result = await this.agent!.invoke({
input: { question: prompt },
options: { maxTokens: 512, temperature: 0.5 }
});
return {
type: 'query',
message: result.data?.answer || '抱歉,我没有理解您的问题',
confidence: 0.6
};
}
/**
* 主动建议
* 基于上下文主动推送建议
*/
async generateProactiveSuggestions(context: HomeContext): Promise<<HomeResponse[]> {
const suggestions: HomeResponse[] = [];
// 能耗建议
if (context.energyStatus.efficiency < 60) {
suggestions.push({
type: 'suggestion',
message: `检测到能耗较高,建议将空调温度调高1℃可节省约8%电费`,
actions: [{ deviceId: 'ac_001', action: 'set_temperature', value: (context.activeDevices.find(d => d.id === 'ac_001')?.status.temperature || 26) + 1, reason: '节能建议' }],
confidence: 0.8
});
}
// 安防建议
if (context.securityStatus === 'safe' && context.timeContext.hour >= 23) {
suggestions.push({
type: 'suggestion',
message: '夜深了,建议开启夜间安防模式',
actions: [{ deviceId: 'camera_001', action: 'turn_on', value: { mode: 'night' }, reason: '夜间安防' }],
confidence: 0.7
});
}
// 舒适建议
if (context.environment.temperature > 30 && context.timeContext.season === 'summer') {
suggestions.push({
type: 'suggestion',
message: `室内温度较高(${context.environment.temperature}℃),建议开启空调或调整窗帘`,
actions: [
{ deviceId: 'ac_001', action: 'turn_on', value: { temperature: 26 }, reason: '降温' },
{ deviceId: 'curtain_001', action: 'close', value: null, reason: '遮阳' }
],
confidence: 0.85
});
}
return suggestions;
}
private mapAction(action: string): string {
const map: Record<string, string> = {
'开': 'turn_on',
'关': 'turn_off',
'打开': 'turn_on',
'关闭': 'turn_off',
'调亮': 'set_brightness',
'调暗': 'set_brightness',
'调高': 'set_temperature',
'调低': 'set_temperature'
};
return map[action] || action;
}
private parseValue(value: string, action: string): any {
if (!value) return null;
const numMatch = value.match(/\d+/);
if (numMatch) {
const num = parseInt(numMatch[0]);
if (action.includes('brightness')) return num;
if (action.includes('temperature')) return num;
return num;
}
return value;
}
destroy(): void {
this.agent?.destroy();
}
}
4.4 悬浮窗家居控制面板(HomeFloatWindow)
// float/HomeFloatWindow.ets
import { window } from '@kit.ArkUI';
import { emitter } from '@kit.BasicServicesKit';
import { HomeContext, SmartDevice } from '../engine/HomeContextEngine';
import { HomeResponse } from '../agent/HomeAgentEngine';
export class HomeFloatWindow {
private floatWin: window.Window | null = null;
private currentLevel: 'capsule' | 'panel' = 'capsule';
async create(): Promise<void> {
const option: window.WindowOption = {
name: 'SmartHomeHub',
windowType: window.WindowType.TYPE_FLOAT,
ctx: getContext(this)
};
this.floatWin = await window.createWindow(getContext(this), option);
// 胶囊形态:显示核心状态
await this.floatWin.resize({ width: 100, height: 100 });
await this.floatWin.moveWindowTo({ x: 950, y: 150 });
await this.floatWin.setWindowTouchable(true);
await this.floatWin.setUIContent('pages/HomeCapsulePage');
await this.floatWin.showWindow();
}
async expandToPanel(context: HomeContext): Promise<void> {
if (!this.floatWin) return;
this.currentLevel = 'panel';
await this.floatWin.resize({ width: 460, height: 780 });
await this.floatWin.moveWindowTo({ x: 540, y: 60 });
await this.floatWin.setUIContent('pages/HomePanelPage');
emitter.emit('showHomePanel', { data: context });
}
async autoExpandOnAlert(context: HomeContext): Promise<void> {
if (!this.floatWin || this.currentLevel !== 'capsule') return;
if (context.securityStatus === 'emergency' || context.securityStatus === 'alert') {
await this.expandToPanel(context);
}
}
async collapseToCapsule(): Promise<void> {
if (!this.floatWin) return;
this.currentLevel = 'capsule';
await this.floatWin.resize({ width: 100, height: 100 });
await this.floatWin.moveWindowTo({ x: 950, y: 150 });
await this.floatWin.setUIContent('pages/HomeCapsulePage');
}
destroy(): void {
this.floatWin?.destroyWindow();
}
}
4.5 家居胶囊页面(HomeCapsulePage)
// pages/HomeCapsulePage.ets
import { emitter } from '@kit.BasicServicesKit';
import { SecurityLevel } from '../engine/HomeContextEngine';
@Entry
@Component
struct HomeCapsulePage {
@State securityStatus: SecurityLevel = SecurityLevel.SAFE;
@State activeDeviceCount: number = 0;
@State temperature: number = 24;
@State isListening: boolean = false;
private securityIcons: Record<<SecurityLevel, string> = {
[SecurityLevel.SAFE]: '🔒',
[SecurityLevel.CAUTION]: '⚠️',
[SecurityLevel.ALERT]: '🚨',
[SecurityLevel.EMERGENCY]: '‼️'
};
aboutToAppear() {
emitter.on('updateHomeContext', (event) => {
const ctx = event.data;
this.securityStatus = ctx?.securityStatus || SecurityLevel.SAFE;
this.activeDeviceCount = ctx?.activeDevices?.length || 0;
this.temperature = ctx?.environment?.temperature || 24;
});
}
build() {
Stack() {
// 安防告警脉冲
if (this.securityStatus === SecurityLevel.ALERT || this.securityStatus === SecurityLevel.EMERGENCY) {
Circle()
.width(110)
.height(110)
.fill(this.securityStatus === SecurityLevel.EMERGENCY ? '#FF1744' : '#FF9100')
.opacity(0.2)
.animation({
duration: this.securityStatus === SecurityLevel.EMERGENCY ? 500 : 1000,
iterations: -1,
curve: Curve.EaseInOut,
playMode: PlayMode.Alternate
})
}
Column() {
// 安防图标
Text(this.securityIcons[this.securityStatus])
.fontSize(28)
// 温度
Text(`${this.temperature}℃`)
.fontSize(14)
.fontColor('#666')
.margin({ top: 2 })
// 活跃设备数
Text(`${this.activeDeviceCount}设备`)
.fontSize(10)
.fontColor('#999')
}
.width(100)
.height(100)
.justifyContent(FlexAlign.Center)
.backgroundColor('rgba(255, 255, 255, 0.95)')
.borderRadius(50)
.shadow({ radius: 15, color: 'rgba(0,0,0,0.12)' })
.gesture(
GestureGroup(GestureMode.Sequence,
TapGesture({ count: 1 })
.onAction(() => emitter.emit('expandToPanel')),
LongPressGesture({ duration: 800 })
.onAction(() => this.toggleVoiceMode())
)
)
}
.width('100%')
.height('100%')
.align(Alignment.Center)
}
private toggleVoiceMode() {
this.isListening = !this.isListening;
emitter.emit('toggleVoiceMode', { data: { active: this.isListening } });
}
}
4.6 家居面板页面(HomePanelPage)
// pages/HomePanelPage.ets
import { emitter } from '@kit.BasicServicesKit';
import { HomeContext, SmartDevice, DeviceType, SecurityLevel } from '../engine/HomeContextEngine';
import { HomeResponse } from '../agent/HomeAgentEngine';
@Entry
@Component
struct HomePanelPage {
@State context: HomeContext | null = null;
@State selectedRoom: string = 'all';
@State isVoiceMode: boolean = false;
@State voiceText: string = '';
private roomFilters: string[] = ['all', 'living_room', 'bedroom', 'kitchen'];
aboutToAppear() {
emitter.on('showHomePanel', (event) => {
this.context = event.data;
});
}
build() {
Column() {
// 顶部标题栏
Row() {
Text('🏠 智能家居')
.fontSize(18)
.fontWeight(FontWeight.Bold)
.layoutWeight(1)
Button(this.isVoiceMode ? '🎤' : '⌨️')
.fontSize(14)
.backgroundColor('#f0f0f0')
.onClick(() => this.isVoiceMode = !this.isVoiceMode)
Button('收起')
.fontSize(12)
.backgroundColor('#f0f0f0')
.fontColor('#333')
.margin({ left: 8 })
.onClick(() => emitter.emit('collapseToCapsule'))
}
.width('100%')
.padding(16)
// 环境状态卡片
Row() {
Column() {
Text('🌡️')
.fontSize(24)
Text(`${this.context?.environment?.temperature || 24}℃`)
.fontSize(16)
.fontWeight(FontWeight.Medium)
Text('温度')
.fontSize(10)
.fontColor('#999')
}
.layoutWeight(1)
Column() {
Text('💧')
.fontSize(24)
Text(`${this.context?.environment?.humidity || 50}%`)
.fontSize(16)
.fontWeight(FontWeight.Medium)
Text('湿度')
.fontSize(10)
.fontColor('#999')
}
.layoutWeight(1)
Column() {
Text('💡')
.fontSize(24)
Text(`${this.context?.environment?.illuminance || 300}lx`)
.fontSize(16)
.fontWeight(FontWeight.Medium)
Text('光照')
.fontSize(10)
.fontColor('#999')
}
.layoutWeight(1)
Column() {
Text('🌬️')
.fontSize(24)
Text(`${this.context?.environment?.airQuality || 85}`)
.fontSize(16)
.fontWeight(FontWeight.Medium)
Text('空气')
.fontSize(10)
.fontColor('#999')
}
.layoutWeight(1)
}
.width('100%')
.padding(12)
.backgroundColor('#f8f9fa')
.borderRadius(12)
.margin({ bottom: 12 })
// 安防状态
if (this.context?.securityStatus !== SecurityLevel.SAFE) {
Row() {
Text(this.context?.securityStatus === SecurityLevel.EMERGENCY ? '‼️' : '🚨')
.fontSize(20)
Text(`安防${this.context?.securityStatus === SecurityLevel.EMERGENCY ? '紧急' : '警戒'}状态`)
.fontSize(14)
.fontColor('#FFF')
.fontWeight(FontWeight.Bold)
.layoutWeight(1)
.margin({ left: 8 })
Button('查看详情')
.fontSize(12)
.backgroundColor('#FFF')
.fontColor('#FF1744')
.onClick(() => this.viewSecurityDetails())
}
.width('100%')
.padding(12)
.backgroundColor(
this.context?.securityStatus === SecurityLevel.EMERGENCY ? '#FF1744' : '#FF9100'
)
.borderRadius(8)
.margin({ bottom: 12 })
}
// 房间筛选
Row() {
ForEach(this.roomFilters, (room: string) => {
Button(this.getRoomName(room))
.fontSize(12)
.backgroundColor(this.selectedRoom === room ? '#2979FF' : '#f0f0f0')
.fontColor(this.selectedRoom === room ? '#FFF' : '#666')
.margin({ right: 8 })
.onClick(() => this.selectedRoom = room)
})
}
.width('100%')
.margin({ bottom: 12 })
// 设备列表
List() {
ForEach(this.filteredDevices(), (device: SmartDevice) => {
ListItem() {
this.DeviceCard(device)
}
})
}
.width('100%')
.layoutWeight(1)
// 快速场景
Row() {
Button('🏠 回家')
.fontSize(12)
.backgroundColor('#E8F5E9')
.fontColor('#2E7D32')
.layoutWeight(1)
.onClick(() => this.activateScene('home'))
Button('😴 睡眠')
.fontSize(12)
.backgroundColor('#E3F2FD')
.fontColor('#1565C0')
.margin({ left: 8 })
.layoutWeight(1)
.onClick(() => this.activateScene('sleep'))
Button('🎬 观影')
.fontSize(12)
.backgroundColor('#F3E5F5')
.fontColor('#7B1FA2')
.margin({ left: 8 })
.layoutWeight(1)
.onClick(() => this.activateScene('movie'))
Button('🚪 离家')
.fontSize(12)
.backgroundColor('#FFEBEE')
.fontColor('#C62828')
.margin({ left: 8 })
.layoutWeight(1)
.onClick(() => this.activateScene('away'))
}
.width('100%')
.padding({ top: 12 })
// 语音输入
if (this.isVoiceMode) {
Row() {
TextInput({ placeholder: '语音输入或打字指令...', text: this.voiceText })
.fontSize(14)
.layoutWeight(1)
.onSubmit((value) => this.submitCommand(value))
Button('🎤')
.fontSize(14)
.backgroundColor('#2979FF')
.onClick(() => this.startVoiceInput())
}
.width('100%')
.padding(12)
.backgroundColor('#f8f9fa')
.borderRadius(8)
.margin({ top: 8 })
}
}
.width('100%')
.height('100%')
.padding(16)
.backgroundColor('#FFF')
.borderRadius(16)
}
@Builder
DeviceCard(device: SmartDevice) {
Row() {
Text(this.getDeviceIcon(device.type))
.fontSize(24)
.margin({ right: 12 })
Column() {
Text(device.name)
.fontSize(14)
.fontWeight(FontWeight.Medium)
.width('100%')
Text(this.getDeviceStatusText(device))
.fontSize(12)
.fontColor('#666')
.width('100%')
}
.layoutWeight(1)
Toggle({ type: ToggleType.Switch, isOn: device.status.power === 'on' })
.selectedColor('#2979FF')
.onChange((isOn) => {
emitter.emit('controlDevice', {
data: {
deviceId: device.id,
action: isOn ? 'turn_on' : 'turn_off'
}
});
})
if (device.status.brightness !== undefined) {
Slider({
value: device.status.brightness,
min: 0,
max: 100
})
.width(80)
.onChange((value) => {
emitter.emit('controlDevice', {
data: { deviceId: device.id, action: 'set_brightness', value }
});
})
}
}
.width('100%')
.padding(12)
.backgroundColor('#fff')
.borderRadius(8)
.margin({ bottom: 8 })
.shadow({ radius: 4, color: 'rgba(0,0,0,0.05)' })
}
private filteredDevices(): SmartDevice[] {
if (!this.context?.activeDevices) return [];
if (this.selectedRoom === 'all') return this.context.activeDevices;
return this.context.activeDevices.filter(d => d.location === this.selectedRoom);
}
private getRoomName(room: string): string {
const names: Record<string, string> = {
'all': '全部',
'living_room': '客厅',
'bedroom': '卧室',
'kitchen': '厨房'
};
return names[room] || room;
}
private getDeviceIcon(type: DeviceType): string {
const icons: Record<string, string> = {
'light': '💡',
'air_conditioner': '❄️',
'curtain': '🪟',
'camera': '📷',
'smart_lock': '🔐',
'sensor': '📡',
'switch': '🔘',
'speaker': '🔊'
};
return icons[type] || '📟';
}
private getDeviceStatusText(device: SmartDevice): string {
if (device.status.power === 'off') return '已关闭';
if (device.status.temperature !== undefined) return `${device.status.temperature}℃`;
if (device.status.brightness !== undefined) return `亮度 ${device.status.brightness}%`;
return '运行中';
}
private viewSecurityDetails() {
emitter.emit('viewSecurityDetails');
}
private activateScene(scene: string) {
emitter.emit('activateScene', { data: { scene } });
}
private submitCommand(command: string) {
emitter.emit('processCommand', { data: { command } });
this.voiceText = '';
}
private startVoiceInput() {
emitter.emit('startVoiceInput');
}
}
4.7 主入口与系统集成(Index.ets)
// Index.ets
import { HomeContextEngine, SecurityLevel } from './engine/HomeContextEngine';
import { HomeLightingController } from './lighting/HomeLightingController';
import { HomeFloatWindow } from './float/HomeFloatWindow';
import { HomeAgentEngine } from './agent/HomeAgentEngine';
import { emitter } from '@kit.BasicServicesKit';
@Entry
@Component
struct SmartHomeApp {
private homeEngine: HomeContextEngine = new HomeContextEngine();
private lightController: HomeLightingController = new HomeLightingController();
private floatWindow: HomeFloatWindow = new HomeFloatWindow();
private agentEngine: HomeAgentEngine = new HomeAgentEngine();
aboutToAppear() {
this.initSystem();
}
aboutToDisappear() {
this.homeEngine.destroy();
this.lightController.reset();
this.floatWindow.destroy();
this.agentEngine.destroy();
}
async initSystem() {
// 1. 初始化沉浸光感
await this.lightController.init();
// 2. 初始化悬浮窗
await this.floatWindow.create();
// 3. 初始化智能体引擎
await this.agentEngine.init();
// 4. 初始化家居引擎
await this.homeEngine.init();
// 当家居上下文变化时,更新光效和悬浮窗
this.homeEngine.onContextChange(async (context) => {
// 更新光效
await this.lightController.updateByContext({
security: context.securityStatus,
energy: context.energyStatus,
environment: context.environment,
time: context.timeContext,
location: context.location
});
// 严重告警自动展开
await this.floatWindow.autoExpandOnAlert(context);
// 更新悬浮窗
emitter.emit('updateHomeContext', { data: context });
// 生成主动建议
const suggestions = await this.agentEngine.generateProactiveSuggestions(context);
if (suggestions.length > 0) {
// 推送建议到悬浮窗
emitter.emit('proactiveSuggestions', { data: suggestions });
}
});
// 5. 设置事件监听
this.setupEventListeners();
}
private setupEventListeners() {
emitter.on('expandToPanel', async () => {
const context = this.homeEngine.getCurrentContext();
if (context) {
await this.floatWindow.expandToPanel(context);
}
});
emitter.on('collapseToCapsule', async () => {
await this.floatWindow.collapseToCapsule();
});
emitter.on('controlDevice', async (event) => {
const { deviceId, action, value } = event.data || {};
const success = await this.homeEngine.controlDevice(deviceId, action, value);
await this.lightController.controlFeedback(success);
});
emitter.on('activateScene', async (event) => {
const scene = event.data?.scene;
const context = this.homeEngine.getCurrentContext();
if (scene && context) {
const response = await this.agentEngine.processCommand(`切换到${scene}模式`, context);
if (response.actions) {
for (const action of response.actions) {
await this.homeEngine.controlDevice(action.deviceId, action.action, action.value);
}
}
await this.lightController.sceneTransition(scene);
}
});
emitter.on('processCommand', async (event) => {
const command = event.data?.command;
const context = this.homeEngine.getCurrentContext();
if (command && context) {
const response = await this.agentEngine.processCommand(command, context);
// 执行控制动作
if (response.actions) {
for (const action of response.actions) {
await this.homeEngine.controlDevice(action.deviceId, action.action, action.value);
}
}
// 显示回复
// ...
}
});
emitter.on('toggleVoiceMode', (event) => {
// 切换语音模式
});
}
build() {
Column() {
Text('🏠 HarmonyOS智能家居中枢')
.fontSize(24)
.fontWeight(FontWeight.Bold)
.margin({ bottom: 8 })
Text('AI智能体正在守护您的家...')
.fontSize(14)
.fontColor('#666')
Text('悬浮窗常驻显示,语音/手势随时控制')
.fontSize(12)
.fontColor('#999')
.margin({ top: 4 })
.textAlign(TextAlign.Center)
// 家居概览
Column() {
Text('📊 家居概览')
.fontSize(16)
.fontWeight(FontWeight.Medium)
.margin({ bottom: 12 })
Row() {
Column() {
Text('12')
.fontSize(28)
.fontWeight(FontWeight.Bold)
.fontColor('#2979FF')
Text('在线设备')
.fontSize(12)
.fontColor('#999')
}
.layoutWeight(1)
Column() {
Text('🔒')
.fontSize(28)
Text('安全')
.fontSize(12)
.fontColor('#999')
}
.layoutWeight(1)
Column() {
Text('24℃')
.fontSize(28)
.fontWeight(FontWeight.Bold)
.fontColor('#00C853')
Text('舒适')
.fontSize(12)
.fontColor('#999')
}
.layoutWeight(1)
}
.width('100%')
}
.width('90%')
.padding(20)
.backgroundColor('#f8f9fa')
.borderRadius(12)
.margin({ top: 32 })
// 当前状态
Row() {
Text('系统状态:')
.fontSize(14)
.fontColor('#666')
Text('🟢 正常运行')
.fontSize(14)
.fontColor('#00C853')
.fontWeight(FontWeight.Medium)
}
.margin({ top: 20 })
}
.width('100%')
.height('100%')
.justifyContent(FlexAlign.Center)
}
}
五、配置文件
// module.json5
{
"module": {
"name": "SmartHomeHub",
"type": "entry",
"description": "鸿蒙智能体智能家居控制中枢",
"mainElement": "EntryAbility",
"deviceTypes": ["phone", "tablet", "2in1"],
"pages": "$profile:main_pages",
"abilities": [
{
"name": "EntryAbility",
"srcEntry": "./ets/entryability/EntryAbility.ets",
"description": "智能家居中枢主入口",
"icon": "$media:layered_image",
"label": "AI智能家居",
"startWindowIcon": "$media:startIcon",
"startWindowBackground": "$color:start_window_background",
"exported": true,
"skills": [
{
"entities": ["entity.system.home"],
"actions": ["action.system.home"]
}
]
}
],
"requestPermissions": [
{
"name": "ohos.permission.SYSTEM_FLOAT_WINDOW",
"reason": "需要悬浮窗权限以常驻显示家居状态"
},
{
"name": "ohos.permission.DISTRIBUTED_DEVICE_STATE_CHANGE",
"reason": "需要分布式设备状态变更权限"
},
{
"name": "ohos.permission.ACCESS_SENSORS",
"reason": "读取环境传感器数据"
},
{
"name": "ohos.permission.INTERNET",
"reason": "连接云端智能体服务"
},
{
"name": "ohos.permission.ACCESS_AI_MODEL",
"reason": "使用端侧AI模型进行语义理解"
},
{
"name": "ohos.permission.MICROPHONE",
"reason": "支持语音控制交互"
}
]
}
}
六、效果展示与使用场景
6.1 典型家居场景
场景A:烹饪助手
用户在厨房做饭,双手沾满面粉。语音说"把厨房灯调亮一点",悬浮窗AI智能体识别指令,自动将厨房灯光从50%调至80%,边框泛起温暖的橙色光效表示"烹饪模式"。同时建议"检测到油烟较大,建议开启抽油烟机"。
场景B:深夜安防
凌晨2点,门口传感器检测到异常震动。设备四周边框立即泛起红色快速脉冲光效,悬浮窗自动展开显示门口摄像头画面。AI智能体分析:“检测到疑似人影,但动作特征与宠物相似,建议查看确认而非直接报警”,避免误报惊扰。
场景C:节能建议
连续三天18:00-20:00空调设定22℃,AI智能体在悬浮窗推送:“检测到您该时段空调温度偏低,调整为26℃可节省15%电费且体感差异不大”,边框泛起绿色光效表示"节能建议"。用户一键采纳,自动调整温度设定。
6.2 光效语义设计
| 家居状态 | 光效表现 | 用户提示 |
|---|---|---|
| 安全正常 | 底部翠绿微光 | 家中安全,放心 |
| 设备运行 | 对应位置柔和色 | 设备正常运行 |
| 能耗良好 | 底部绿色呼吸 | 节能模式运行中 |
| 温度不适 | 全边框红/蓝呼吸 | 建议调节温控 |
| 安防警戒 | 全边框黄色波浪 | 注意查看详情 |
| 安防紧急 | 全边框红色快闪 | 立即处理 |
| 场景切换 | 全边框渐变过渡 | 场景切换中 |
七、性能与隐私优化
7.1 设备连接策略
// 设备连接优化
const deviceStrategy = {
// 连接优先级
priority: ['local_network', 'cloud_relay', 'bluetooth'],
// 心跳间隔
heartbeat: {
normal: 30000, // 正常:30秒
active: 10000, // 活跃:10秒
alert: 5000 // 告警:5秒
},
// 离线缓存
offlineCache: {
enabled: true,
maxCommands: 20, // 最多缓存20条指令
syncOnReconnect: true
}
};
7.2 隐私保护
- 本地优先:所有设备控制优先在本地网络完成
- 数据最小化:仅上传必要的设备状态,不上传用户行为
- 权限隔离:不同家庭成员看到不同的设备权限
- 语音本地识别:常用指令本地识别,敏感操作云端确认
八、总结与展望
本文展示了如何基于HarmonyOS 6(API 23)的悬浮导航和沉浸光感能力,构建一个鸿蒙智能体驱动的沉浸式智能家居控制中枢。与传统智能家居APP不同,它具备三个核心创新:
- 常驻感知:悬浮窗常驻屏幕边缘,家居状态随时可见,语音/手势随时控制
- 光效氛围:通过设备边框光效实现"无屏感知"的家居状态监控
- 情境智能:AI智能体主动学习用户习惯,主动推荐场景化控制方案
未来演进方向:
- 多设备协同:手机悬浮窗 + 平板控制面板 + 音箱语音交互
- 数字孪生:家中3D模型可视化,悬浮窗即数字孪生入口
- 预测性维护:AI预测设备故障,提前安排维修
- 能源优化:结合电网峰谷电价,自动优化用电策略
HarmonyOS 6的智能体框架和系统级交互创新,正在让"AI管家常驻身边"成为现实。对于智能家居用户而言,这不仅是一个控制工具,更是一位24小时在线、懂习惯、懂场景、懂节能的智能生活伙伴。
转载自:https://blog.csdn.net/u014727709/article/details/161367547
欢迎 👍点赞✍评论⭐收藏,欢迎指正
更多推荐




所有评论(0)
