🌌 一、粒子物理系统：从牛顿定律到视觉艺术

📚 1.1 粒子系统的历史与应用

粒子系统（Particle System）是由计算机图形学家**威廉·里夫斯（William Reeves）**在 1983 年提出的，最初用于电影《星际迷航II：可汗之怒》中的火焰效果。如今，粒子系统已成为游戏开发、视觉特效和交互设计中的核心技术。

粒子系统的核心思想是：用大量简单个体的集体行为来模拟复杂现象。每个粒子遵循简单的物理规则，但整体却能产生令人惊叹的视觉效果。

应用领域	具体用途	效果描述
🔥火焰与烟雾	篝火、烟囱、爆炸	粒子上升、扩散、消散
🌊水流效果	喷泉、瀑布、雨滴	重力下落、碰撞溅射
✨星空效果	星云、流星、星系	引力聚集、轨道运动
🎆烟花绽放	节日烟花、礼花	爆炸扩散、拖尾效果
🎵音乐可视化	音频驱动的粒子舞动	随节奏律动、能量爆发

---

📐 1.2 牛顿万有引力定律

牛顿万有引力定律是粒子引力系统的基础：

F = G × (m₁ × m₂) / r²

符号	含义	说明
F	引力大小	两物体间的相互吸引力
G	万有引力常数	6.674×10⁻¹¹ N·m²/kg²
m₁, m₂	物体质量	两物体的质量
r	距离	两物体质心之间的距离

引力方向：沿着两物体连线方向，指向对方。

加速度计算：

a = F / m = G × M / r²

其中 M 是对方的质量。

---

🔬 1.3 力场类型与特性

在粒子系统中，我们可以定义多种力场：

力场类型	公式	特性	视觉效果
🔵引力场	F ∝ 1/r²	远距离衰减	聚集、轨道
🔴斥力场	F ∝ -1/r²	远距离衰减	扩散、排斥
🟢弹簧力	F = -kx	线性恢复	弹性、振荡
🟡阻力	F = -bv	速度衰减	阻尼、稳定
🟣涡流场	F ⊥ r	切向力	旋转、螺旋

力场方向示意：

引力场：  ● ←───────→ ●  (相互吸引)
斥力场：  ● ──────→ ←────── ●  (相互排斥)
涡流场：     ↻ ↺
              ●

---

🎯 1.4 粒子系统的核心组件

一个完整的粒子系统包含以下核心组件：

组件	职责	关键属性
🎯粒子	基本单元	位置、速度、加速度、质量、颜色、生命周期
⚡力场	施加力	类型、强度、范围、衰减
🔄发射器	生成粒子	位置、速率、方向、初始速度
🎨渲染器	绘制粒子	形状、大小、透明度、混合模式
⏱️更新器	状态更新	积分方法、碰撞检测、边界处理

---

🔧 二、粒子物理系统的 Dart 实现

🧮 2.1 粒子基础类

import 'dart:math';
import 'dart:typed_data';

/// 二维向量
class Vector2D {
  double x;
  double y;

  Vector2D(this.x, this.y);

  factory Vector2D.zero() => Vector2D(0, 0);
  factory Vector2D.fromAngle(double angle, double magnitude) =>
      Vector2D(cos(angle) * magnitude, sin(angle) * magnitude);

  Vector2D operator +(Vector2D other) => Vector2D(x + other.x, y + other.y);
  Vector2D operator -(Vector2D other) => Vector2D(x - other.x, y - other.y);
  Vector2D operator *(double scalar) => Vector2D(x * scalar, y * scalar);
  Vector2D operator /(double scalar) => Vector2D(x / scalar, y / scalar);

  void add(Vector2D other) {
    x += other.x;
    y += other.y;
  }

  void multiply(double scalar) {
    x *= scalar;
    y *= scalar;
  }

  double get magnitude => sqrt(x * x + y * y);
  double get angle => atan2(y, x);

  Vector2D get normalized {
    final mag = magnitude;
    return mag > 0 ? this / mag : Vector2D.zero();
  }

  Vector2D get perpendicular => Vector2D(-y, x);

  double dot(Vector2D other) => x * other.x + y * other.y;

  void limit(double max) {
    final mag = magnitude;
    if (mag > max) {
      multiply(max / mag);
    }
  }

  void setMagnitude(double mag) {
    final currentMag = magnitude;
    if (currentMag > 0) {
      multiply(mag / currentMag);
    }
  }
}

/// 粒子类
class Particle {
  Vector2D position;
  Vector2D velocity;
  Vector2D acceleration;
  double mass;
  double radius;
  Color color;
  double life;
  double maxLife;
  bool isAlive;

  Particle({
    required this.position,
    Vector2D? velocity,
    Vector2D? acceleration,
    this.mass = 1.0,
    this.radius = 5.0,
    this.color = Colors.white,
    this.maxLife = 5.0,
  })  : velocity = velocity ?? Vector2D.zero(),
        acceleration = acceleration ?? Vector2D.zero(),
        life = maxLife,
        isAlive = true;

  /// 施加力
  void applyForce(Vector2D force) {
    // F = ma, a = F/m
    acceleration.add(force / mass);
  }

  /// 更新状态
  void update(double dt) {
    // 速度积分
    velocity.add(acceleration * dt);

    // 位置积分
    position.add(velocity * dt);

    // 重置加速度（每帧重新计算）
    acceleration = Vector2D.zero();

    // 生命周期
    life -= dt;
    if (life <= 0) {
      isAlive = false;
    }
  }

  /// 获取生命比例
  double get lifeRatio => life / maxLife;

  /// 获取透明度
  double get opacity => lifeRatio.clamp(0.0, 1.0);
}

/// 粒子系统
class ParticleSystem {
  final List<Particle> particles = [];
  final List<ForceField> forceFields = [];
  final Random random = Random();

  int maxParticles;
  Vector2D gravity;
  double damping;

  ParticleSystem({
    this.maxParticles = 500,
    this.gravity = const Vector2D(0, 0),
    this.damping = 0.99,
  });

  /// 添加粒子
  void addParticle(Particle particle) {
    if (particles.length < maxParticles) {
      particles.add(particle);
    }
  }

  /// 添加力场
  void addForceField(ForceField field) {
    forceFields.add(field);
  }

  /// 更新所有粒子
  void update(double dt) {
    // 计算并施加力
    for (final particle in particles) {
      // 重力
      particle.applyForce(gravity * particle.mass);

      // 力场作用
      for (final field in forceFields) {
        final force = field.calculateForce(particle);
        particle.applyForce(force);
      }

      // 阻尼
      particle.velocity.multiply(damping);
    }

    // 更新粒子状态
    for (final particle in particles) {
      particle.update(dt);
    }

    // 移除死亡粒子
    particles.removeWhere((p) => !p.isAlive);
  }

  /// 清除所有粒子
  void clear() {
    particles.clear();
  }
}

---

⚡ 2.2 力场实现

/// 力场基类
abstract class ForceField {
  Vector2D position;
  double strength;
  double range;
  bool enabled;

  ForceField({
    required this.position,
    required this.strength,
    this.range = double.infinity,
    this.enabled = true,
  });

  Vector2D calculateForce(Particle particle);
}

/// 引力场
class GravityField extends ForceField {
  double mass;

  GravityField({
    required super.position,
    required this.mass,
    super.range,
  }) : super(strength: mass);

  @override
  Vector2D calculateForce(Particle particle) {
    if (!enabled) return Vector2D.zero();

    final direction = position - particle.position;
    final distance = direction.magnitude;

    // 避免距离过近导致力过大
    final minDistance = 10.0;
    final effectiveDistance = max(distance, minDistance);

    // 检查范围
    if (range != double.infinity && effectiveDistance > range) {
      return Vector2D.zero();
    }

    // F = G * m1 * m2 / r^2
    // 这里简化为 F = strength * m / r^2
    final forceMagnitude = strength * particle.mass / (effectiveDistance * effectiveDistance);

    // 限制最大力
    final maxForce = 100.0;
    final clampedForce = min(forceMagnitude, maxForce);

    return direction.normalized * clampedForce;
  }
}

/// 斥力场
class RepulsionField extends ForceField {
  RepulsionField({
    required super.position,
    required super.strength,
    super.range,
  });

  @override
  Vector2D calculateForce(Particle particle) {
    if (!enabled) return Vector2D.zero();

    final direction = particle.position - position;
    final distance = direction.magnitude;

    // 避免距离过近导致力过大
    final minDistance = 5.0;
    final effectiveDistance = max(distance, minDistance);

    // 检查范围
    if (range != double.infinity && effectiveDistance > range) {
      return Vector2D.zero();
    }

    // 斥力与距离平方成反比
    final forceMagnitude = strength / (effectiveDistance * effectiveDistance);

    // 限制最大力
    final maxForce = 200.0;
    final clampedForce = min(forceMagnitude, maxForce);

    return direction.normalized * clampedForce;
  }
}

/// 涡流场
class VortexField extends ForceField {
  double angularStrength;

  VortexField({
    required super.position,
    required super.strength,
    this.angularStrength = 1.0,
    super.range,
  });

  @override
  Vector2D calculateForce(Particle particle) {
    if (!enabled) return Vector2D.zero();

    final direction = position - particle.position;
    final distance = direction.magnitude;

    // 检查范围
    if (range != double.infinity && distance > range) {
      return Vector2D.zero();
    }

    // 切向力（旋转）
    final tangent = direction.perpendicular.normalized;

    // 径向力（吸引/排斥）
    final radial = direction.normalized;

    // 组合力
    final radialStrength = strength / max(distance, 10);
    final tangentialStrength = angularStrength / max(distance, 10);

    return tangent * tangentialStrength + radial * radialStrength;
  }
}

/// 均匀力场（如风力）
class UniformField extends ForceField {
  Vector2D direction;

  UniformField({
    required this.direction,
    required super.strength,
  }) : super(position: Vector2D.zero());

  @override
  Vector2D calculateForce(Particle particle) {
    if (!enabled) return Vector2D.zero();
    return direction.normalized * strength;
  }
}

---

🎨 2.3 粒子发射器

/// 粒子发射器
class ParticleEmitter {
  Vector2D position;
  double emissionRate;
  double initialSpeed;
  double speedVariation;
  double direction;
  double spread;
  double initialLife;
  double lifeVariation;
  double initialMass;
  double massVariation;
  double initialRadius;
  double radiusVariation;
  Color color;
  List<Color> colorVariations;

  final Random _random = Random();

  ParticleEmitter({
    required this.position,
    this.emissionRate = 10,
    this.initialSpeed = 50,
    this.speedVariation = 20,
    this.direction = 0,
    this.spread = pi / 4,
    this.initialLife = 3,
    this.lifeVariation = 1,
    this.initialMass = 1,
    this.massVariation = 0.5,
    this.initialRadius = 5,
    this.radiusVariation = 2,
    this.color = Colors.white,
    this.colorVariations = const [],
  });

  /// 发射粒子
  List<Particle> emit(double dt) {
    final particles = <Particle>[];
    final count = (emissionRate * dt).floor();

    for (int i = 0; i < count; i++) {
      particles.add(_createParticle());
    }

    // 概率性发射额外粒子
    if (_random.nextDouble() < (emissionRate * dt) % 1) {
      particles.add(_createParticle());
    }

    return particles;
  }

  Particle _createParticle() {
    // 随机角度
    final angle = direction + (_random.nextDouble() - 0.5) * spread;

    // 随机速度
    final speed = initialSpeed + (_random.nextDouble() - 0.5) * speedVariation;

    // 随机生命周期
    final life = initialLife + (_random.nextDouble() - 0.5) * lifeVariation;

    // 随机质量
    final mass = initialMass + (_random.nextDouble() - 0.5) * massVariation;

    // 随机半径
    final radius = initialRadius + (_random.nextDouble() - 0.5) * radiusVariation;

    // 随机颜色
    Color particleColor = color;
    if (colorVariations.isNotEmpty) {
      particleColor = colorVariations[_random.nextInt(colorVariations.length)];
    }

    return Particle(
      position: Vector2D(position.x, position.y),
      velocity: Vector2D.fromAngle(angle, speed),
      mass: mass,
      radius: radius,
      color: particleColor,
      maxLife: life,
    );
  }

  /// 爆发式发射
  List<Particle> burst(int count) {
    return List.generate(count, (_) => _createParticle());
  }
}

---

🌬️ 三、音乐驱动的引力场动画

🎵 3.1 音频响应的引力系统

import 'package:flutter/material.dart';
import 'package:just_audio_ohos/just_audio_ohos.dart';
import 'package:audio_session/audio_session.dart';

/// 音频驱动的引力场控制器
class AudioGravityController extends ChangeNotifier {
  final AudioPlayer _player = AudioPlayer();
  final ParticleSystem _particleSystem = ParticleSystem(
    maxParticles: 800,
    damping: 0.98,
  );

  bool _isPlaying = false;
  Duration _position = Duration.zero;
  Duration _duration = Duration.zero;

  // 音频特征
  Float32List _audioData = Float32List(128);
  double _energy = 0;
  double _bass = 0;
  double _mid = 0;
  double _treble = 0;

  // 引力场参数
  final List<GravityField> _gravityFields = [];
  final List<RepulsionField> _repulsionFields = [];
  final List<VortexField> _vortexFields = [];

  bool get isPlaying => _isPlaying;
  Duration get position => _position;
  Duration get duration => _duration;
  ParticleSystem get particleSystem => _particleSystem;
  Float32List get audioData => _audioData;
  double get energy => _energy;
  double get bass => _bass;
  double get mid => _mid;
  double get treble => _treble;
  List<GravityField> get gravityFields => _gravityFields;
  List<RepulsionField> get repulsionFields => _repulsionFields;
  List<VortexField> get vortexFields => _vortexFields;
  AudioPlayer get player => _player;

  /// 初始化
  Future<void> initialize() async {
    final session = await AudioSession.instance;
    await session.configure(const AudioSessionConfiguration.music());

    _player.playerStateStream.listen((state) {
      _isPlaying = state.playing;
      notifyListeners();
    });

    _player.positionStream.listen((position) {
      _position = position;
      notifyListeners();
    });

    _player.durationStream.listen((duration) {
      _duration = duration ?? Duration.zero;
      notifyListeners();
    });
  }

  /// 加载网络音频
  Future<void> loadAudio(String url) async {
    try {
      await _player.setUrl(url);
    } catch (e) {
      debugPrint('加载音频失败: $e');
    }
  }

  /// 设置力场
  void setupForceFields(Size size) {
    _gravityFields.clear();
    _repulsionFields.clear();
    _vortexFields.clear();

    final centerX = size.width / 2;
    final centerY = size.height / 2;

    // 中心引力场
    _gravityFields.add(GravityField(
      position: Vector2D(centerX, centerY),
      mass: 500,
      range: 300,
    ));

    // 四角斥力场
    _repulsionFields.add(RepulsionField(
      position: Vector2D(50, 50),
      strength: 1000,
      range: 100,
    ));
    _repulsionFields.add(RepulsionField(
      position: Vector2D(size.width - 50, 50),
      strength: 1000,
      range: 100,
    ));
    _repulsionFields.add(RepulsionField(
      position: Vector2D(50, size.height - 50),
      strength: 1000,
      range: 100,
    ));
    _repulsionFields.add(RepulsionField(
      position: Vector2D(size.width - 50, size.height - 50),
      strength: 1000,
      range: 100,
    ));

    // 涡流场
    _vortexFields.add(VortexField(
      position: Vector2D(centerX - 100, centerY),
      strength: 50,
      angularStrength: 100,
      range: 150,
    ));
    _vortexFields.add(VortexField(
      position: Vector2D(centerX + 100, centerY),
      strength: 50,
      angularStrength: -100,
      range: 150,
    ));

    // 添加到粒子系统
    _particleSystem.forceFields.clear();
    for (final field in _gravityFields) {
      _particleSystem.addForceField(field);
    }
    for (final field in _repulsionFields) {
      _particleSystem.addForceField(field);
    }
    for (final field in _vortexFields) {
      _particleSystem.addForceField(field);
    }
  }

  /// 更新音频数据
  void update(double dt, double time, Size size) {
    final random = Random();

    // 更新音频数据
    for (int i = 0; i < 128; i++) {
      if (_isPlaying) {
        final freq = (i / 128) * 8 + 1;
        final wave1 = sin(time * freq) * 0.4;
        final wave2 = sin(time * freq * 1.5 + pi / 3) * 0.3;
        final wave3 = cos(time * freq * 0.5 + pi / 6) * 0.2;
        final noise = (random.nextDouble() - 0.5) * 0.15;
        final bassBoost = i < 32 ? 0.3 : 0;

        _audioData[i] = _audioData[i] * 0.85 +
            (wave1 + wave2 + wave3 + noise + bassBoost) * 0.15;
      } else {
        _audioData[i] = _audioData[i] * 0.95;
      }
    }

    // 计算音频特征
    _calculateAudioFeatures();

    // 更新力场参数
    _updateForceFields(time, size);

    // 发射粒子
    _emitParticles(time, size);

    // 更新粒子系统
    _particleSystem.update(dt);

    notifyListeners();
  }

  /// 计算音频特征
  void _calculateAudioFeatures() {
    double totalEnergy = 0;
    double bassEnergy = 0;
    double midEnergy = 0;
    double trebleEnergy = 0;

    for (int i = 0; i < 128; i++) {
      final value = _audioData[i].abs();
      totalEnergy += value;

      if (i < 32) {
        bassEnergy += value;
      } else if (i < 96) {
        midEnergy += value;
      } else {
        trebleEnergy += value;
      }
    }

    _energy = totalEnergy / 128;
    _bass = bassEnergy / 32;
    _mid = midEnergy / 64;
    _treble = trebleEnergy / 32;
  }

  /// 更新力场参数
  void _updateForceFields(double time, Size size) {
    final centerX = size.width / 2;
    final centerY = size.height / 2;

    // 中心引力随低音变化
    if (_gravityFields.isNotEmpty) {
      _gravityFields[0].mass = 300 + _bass * 500;
      _gravityFields[0].position = Vector2D(
        centerX + sin(time) * 20 * _energy,
        centerY + cos(time) * 20 * _energy,
      );
    }

    // 涡流场随中频变化
    if (_vortexFields.length >= 2) {
      _vortexFields[0].angularStrength = 50 + _mid * 150;
      _vortexFields[1].angularStrength = -50 - _mid * 150;
    }
  }

  /// 发射粒子
  void _emitParticles(double time, Size size) {
    final centerX = size.width / 2;
    final centerY = size.height / 2;

    // 发射速率随能量变化
    final emissionRate = 10 + _energy * 50;

    // 创建发射器
    final emitter = ParticleEmitter(
      position: Vector2D(centerX, centerY),
      emissionRate: emissionRate,
      initialSpeed: 30 + _energy * 100,
      speedVariation: 20,
      direction: time * 0.5,
      spread: pi * 2,
      initialLife: 4,
      lifeVariation: 2,
      initialRadius: 3 + _bass * 4,
      radiusVariation: 2,
      colorVariations: [
        HSVColor.fromAHSV(1, ((time * 30) % 360).abs(), 0.8, 1).toColor(),
        HSVColor.fromAHSV(1, ((time * 30 + 60) % 360).abs(), 0.8, 1).toColor(),
        HSVColor.fromAHSV(1, ((time * 30 + 120) % 360).abs(), 0.8, 1).toColor(),
      ],
    );

    // 发射粒子
    final newParticles = emitter.emit(0.016);
    for (final particle in newParticles) {
      _particleSystem.addParticle(particle);
    }
  }

  /// 播放/暂停
  Future<void> togglePlay() async {
    if (_isPlaying) {
      await _player.pause();
    } else {
      await _player.play();
    }
  }

  /// 跳转
  Future<void> seek(Duration position) async {
    await _player.seek(position);
  }

  @override
  void dispose() {
    _player.dispose();
    super.dispose();
  }
}

---

🎨 3.2 粒子引力场绘制器

/// 粒子引力场绘制器
class ParticleGravityPainter extends CustomPainter {
  final ParticleSystem particleSystem;
  final List<GravityField> gravityFields;
  final List<RepulsionField> repulsionFields;
  final List<VortexField> vortexFields;
  final double time;
  final double energy;
  final bool isPlaying;

  ParticleGravityPainter({
    required this.particleSystem,
    required this.gravityFields,
    required this.repulsionFields,
    required this.vortexFields,
    required this.time,
    required this.energy,
    required this.isPlaying,
  });

  @override
  void paint(Canvas canvas, Size size) {
    // 绘制背景
    _drawBackground(canvas, size);

    // 绘制力场可视化
    _drawForceFields(canvas, size);

    // 绘制粒子轨迹
    _drawParticleTrails(canvas, size);

    // 绘制粒子
    _drawParticles(canvas, size);

    // 绘制力场中心
    _drawForceFieldCenters(canvas, size);
  }

  void _drawBackground(Canvas canvas, Size size) {
    final gradient = RadialGradient(
      center: Alignment.center,
      radius: 1.0,
      colors: [
        Color.lerp(const Color(0xFF0a0a1a), const Color(0xFF1a0a2a), energy)!,
        const Color(0xFF050510),
      ],
    );

    canvas.drawRect(
      Rect.fromLTWH(0, 0, size.width, size.height),
      Paint()..shader = gradient.createShader(Rect.fromLTWH(0, 0, size.width, size.height)),
    );
  }

  void _drawForceFields(Canvas canvas, Size size) {
    // 绘制引力场范围
    for (final field in gravityFields) {
      final paint = Paint()
        ..color = Colors.blue.withOpacity(0.1 + energy * 0.1)
        ..style = PaintingStyle.stroke
        ..strokeWidth = 1;

      canvas.drawCircle(
        Offset(field.position.x, field.position.y),
        field.range,
        paint,
      );
    }

    // 绘制涡流场
    for (final field in vortexFields) {
      final paint = Paint()
        ..color = Colors.purple.withOpacity(0.15)
        ..style = PaintingStyle.stroke
        ..strokeWidth = 1;

      final path = Path();
      final segments = 50;
      for (int i = 0; i <= segments; i++) {
        final angle = (i / segments) * pi * 4;
        final r = (i / segments) * field.range;
        final x = field.position.x + cos(angle) * r;
        final y = field.position.y + sin(angle) * r;

        if (i == 0) {
          path.moveTo(x, y);
        } else {
          path.lineTo(x, y);
        }
      }

      canvas.drawPath(path, paint);
    }
  }

  void _drawParticleTrails(Canvas canvas, Size size) {
    for (final particle in particleSystem.particles) {
      if (particle.velocity.magnitude > 5) {
        final trailLength = particle.velocity.magnitude * 0.3;
        final trailEnd = particle.position - particle.velocity.normalized * trailLength;

        final paint = Paint()
          ..color = particle.color.withOpacity(particle.opacity * 0.3)
          ..strokeWidth = particle.radius * 0.5
          ..strokeCap = StrokeCap.round;

        canvas.drawLine(
          Offset(particle.position.x, particle.position.y),
          Offset(trailEnd.x, trailEnd.y),
          paint,
        );
      }
    }
  }

  void _drawParticles(Canvas canvas, Size size) {
    for (final particle in particleSystem.particles) {
      final paint = Paint()
        ..color = particle.color.withOpacity(particle.opacity)
        ..style = PaintingStyle.fill;

      // 发光效果
      if (isPlaying && particle.velocity.magnitude > 20) {
        paint.maskFilter = MaskFilter.blur(BlurStyle.normal, particle.radius * 0.5);
      }

      canvas.drawCircle(
        Offset(particle.position.x, particle.position.y),
        particle.radius * (0.5 + particle.lifeRatio * 0.5),
        paint,
      );
    }
  }

  void _drawForceFieldCenters(Canvas canvas, Size size) {
    // 引力场中心
    for (final field in gravityFields) {
      final paint = Paint()
        ..shader = RadialGradient(
          colors: [
            Colors.blue.withOpacity(0.8),
            Colors.blue.withOpacity(0),
          ],
        ).createShader(Rect.fromCircle(
          center: Offset(field.position.x, field.position.y),
          radius: 30,
        ));

      canvas.drawCircle(
        Offset(field.position.x, field.position.y),
        30,
        paint,
      );

      // 核心点
      canvas.drawCircle(
        Offset(field.position.x, field.position.y),
        5,
        Paint()..color = Colors.white,
      );
    }

    // 斥力场中心
    for (final field in repulsionFields) {
      final paint = Paint()
        ..color = Colors.red.withOpacity(0.5 + energy * 0.3)
        ..style = PaintingStyle.stroke
        ..strokeWidth = 2;

      canvas.drawCircle(
        Offset(field.position.x, field.position.y),
        10,
        paint,
      );
    }

    // 涡流场中心
    for (final field in vortexFields) {
      final paint = Paint()
        ..color = Colors.purple.withOpacity(0.8)
        ..style = PaintingStyle.fill;

      canvas.drawCircle(
        Offset(field.position.x, field.position.y),
        8,
        paint,
      );
    }
  }

  @override
  bool shouldRepaint(covariant ParticleGravityPainter oldDelegate) => true;
}

---

📦 四、完整示例代码

以下是完整的粒子物理引力场音乐可视化示例代码，包含网络 MP3 播放功能：

import 'package:flutter/material.dart';
import 'package:just_audio_ohos/just_audio_ohos.dart';
import 'package:audio_session/audio_session.dart';
import 'dart:math';
import 'dart:typed_data';

void main() {
  runApp(const ParticleGravityApp());
}

class ParticleGravityApp extends StatelessWidget {
  const ParticleGravityApp({super.key});

  @override
  Widget build(BuildContext context) {
    return MaterialApp(
      title: '粒子引力场',
      theme: ThemeData(
        colorScheme: ColorScheme.fromSeed(
          seedColor: Colors.indigo,
          brightness: Brightness.dark,
        ),
        useMaterial3: true,
      ),
      home: const ParticleHomePage(),
      debugShowCheckedModeBanner: false,
    );
  }
}

class ParticleHomePage extends StatelessWidget {
  const ParticleHomePage({super.key});

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(
        title: const Text('🌌 粒子引力场'),
        backgroundColor: Theme.of(context).colorScheme.inversePrimary,
      ),
      body: ListView(
        padding: const EdgeInsets.all(16),
        children: [
          _buildSectionCard(
            context,
            title: '基础粒子',
            description: '简单粒子运动演示',
            icon: Icons.blur_circular,
            color: Colors.blue,
            onTap: () => Navigator.push(
              context,
              MaterialPageRoute(builder: (_) => const BasicParticleDemo()),
            ),
          ),
          _buildSectionCard(
            context,
            title: '引力场',
            description: '万有引力模拟',
            icon: Icons.grain,
            color: Colors.indigo,
            onTap: () => Navigator.push(
              context,
              MaterialPageRoute(builder: (_) => const GravityFieldDemo()),
            ),
          ),
          _buildSectionCard(
            context,
            title: '斥力场',
            description: '粒子排斥效果',
            icon: Icons.bubble_chart,
            color: Colors.red,
            onTap: () => Navigator.push(
              context,
              MaterialPageRoute(builder: (_) => const RepulsionFieldDemo()),
            ),
          ),
          _buildSectionCard(
            context,
            title: '涡流场',
            description: '旋转粒子系统',
            icon: Icons.refresh,
            color: Colors.purple,
            onTap: () => Navigator.push(
              context,
              MaterialPageRoute(builder: (_) => const VortexFieldDemo()),
            ),
          ),
          _buildSectionCard(
            context,
            title: '音乐引力场',
            description: '音频驱动的粒子动画',
            icon: Icons.music_note,
            color: Colors.orange,
            onTap: () => Navigator.push(
              context,
              MaterialPageRoute(builder: (_) => const MusicGravityDemo()),
            ),
          ),
          _buildSectionCard(
            context,
            title: '综合演示',
            description: '完整粒子宇宙体验',
            icon: Icons.public,
            color: Colors.cyan,
            onTap: () => Navigator.push(
              context,
              MaterialPageRoute(builder: (_) => const FullGravityDemo()),
            ),
          ),
        ],
      ),
    );
  }

  Widget _buildSectionCard(
    BuildContext context, {
    required String title,
    required String description,
    required IconData icon,
    required Color color,
    required VoidCallback onTap,
  }) {
    return Card(
      margin: const EdgeInsets.only(bottom: 12),
      shape: RoundedRectangleBorder(borderRadius: BorderRadius.circular(16)),
      child: InkWell(
        onTap: onTap,
        borderRadius: BorderRadius.circular(16),
        child: Padding(
          padding: const EdgeInsets.all(16),
          child: Row(
            children: [
              Container(
                width: 56,
                height: 56,
                decoration: BoxDecoration(
                  color: color.withOpacity(0.1),
                  borderRadius: BorderRadius.circular(12),
                ),
                child: Icon(icon, color: color, size: 28),
              ),
              const SizedBox(width: 16),
              Expanded(
                child: Column(
                  crossAxisAlignment: CrossAxisAlignment.start,
                  children: [
                    Text(
                      title,
                      style: const TextStyle(
                        fontSize: 16,
                        fontWeight: FontWeight.bold,
                      ),
                    ),
                    const SizedBox(height: 4),
                    Text(
                      description,
                      style: TextStyle(color: Colors.grey[600], fontSize: 14),
                    ),
                  ],
                ),
              ),
              Icon(Icons.chevron_right, color: Colors.grey[400]),
            ],
          ),
        ),
      ),
    );
  }
}

/// 向量类
class Vector2D {
  double x, y;
  Vector2D(this.x, this.y);

  factory Vector2D.zero() => Vector2D(0, 0);
  factory Vector2D.fromAngle(double angle, double magnitude) =>
      Vector2D(cos(angle) * magnitude, sin(angle) * magnitude);

  Vector2D operator +(Vector2D o) => Vector2D(x + o.x, y + o.y);
  Vector2D operator -(Vector2D o) => Vector2D(x - o.x, y - o.y);
  Vector2D operator *(double s) => Vector2D(x * s, y * s);
  Vector2D operator /(double s) => Vector2D(x / s, y / s);

  void add(Vector2D o) { x += o.x; y += o.y; }
  void multiply(double s) { x *= s; y *= s; }

  double get magnitude => sqrt(x * x + y * y);
  double get angle => atan2(y, x);
  Vector2D get normalized => magnitude > 0 ? this / magnitude : Vector2D.zero();
  Vector2D get perpendicular => Vector2D(-y, x);

  void limit(double max) {
    final mag = magnitude;
    if (mag > max) multiply(max / mag);
  }
}

/// 粒子类
class Particle {
  Vector2D position;
  Vector2D velocity;
  Vector2D acceleration;
  double mass;
  double radius;
  Color color;
  double life;
  double maxLife;
  bool isAlive;

  Particle({
    required this.position,
    Vector2D? velocity,
    this.mass = 1,
    this.radius = 5,
    this.color = Colors.white,
    this.maxLife = 5,
  }) : velocity = velocity ?? Vector2D.zero(),
       acceleration = Vector2D.zero(),
       life = maxLife,
       isAlive = true;

  void applyForce(Vector2D force) => acceleration.add(force / mass);

  void update(double dt) {
    velocity.add(acceleration * dt);
    position.add(velocity * dt);
    acceleration = Vector2D.zero();
    life -= dt;
    if (life <= 0) isAlive = false;
  }

  double get lifeRatio => (life / maxLife).clamp(0.0, 1.0);
}

/// 力场
abstract class ForceField {
  Vector2D position;
  double strength;
  double range;
  ForceField(this.position, this.strength, this.range);
  Vector2D calculateForce(Particle p);
}

/// 引力场
class GravityField extends ForceField {
  GravityField(Vector2D pos, double mass, double range)
      : super(pos, mass, range);

  @override
  Vector2D calculateForce(Particle p) {
    final dir = position - p.position;
    final dist = max(dir.magnitude, 10);
    if (range != double.infinity && dist > range) return Vector2D.zero();
    final force = min(strength * p.mass / (dist * dist), 100).toDouble();
    return dir.normalized * force;
  }
}

/// 斥力场
class RepulsionField extends ForceField {
  RepulsionField(Vector2D pos, double strength, double range)
      : super(pos, strength, range);

  @override
  Vector2D calculateForce(Particle p) {
    final dir = p.position - position;
    final dist = max(dir.magnitude, 5);
    if (range != double.infinity && dist > range) return Vector2D.zero();
    final force = min(strength / (dist * dist), 200).toDouble();
    return dir.normalized * force;
  }
}

/// 涡流场
class VortexField extends ForceField {
  double angularStrength;

  VortexField(Vector2D pos, double strength, this.angularStrength, double range)
      : super(pos, strength, range);

  @override
  Vector2D calculateForce(Particle p) {
    final dir = position - p.position;
    final dist = dir.magnitude;
    if (range != double.infinity && dist > range) return Vector2D.zero();
    final tangent = dir.perpendicular.normalized;
    final radial = dir.normalized;
    return tangent * (angularStrength / max(dist, 10)) +
           radial * (strength / max(dist, 10));
  }
}

/// 粒子系统
class ParticleSystem {
  final List<Particle> particles = [];
  final List<ForceField> forceFields = [];
  int maxParticles;
  double damping;

  ParticleSystem({this.maxParticles = 500, this.damping = 0.99});

  void addParticle(Particle p) {
    if (particles.length < maxParticles) particles.add(p);
  }

  void addForceField(ForceField f) => forceFields.add(f);

  void update(double dt) {
    for (final p in particles) {
      for (final f in forceFields) {
        p.applyForce(f.calculateForce(p));
      }
      p.velocity.multiply(damping);
      p.update(dt);
    }
    particles.removeWhere((p) => !p.isAlive);
  }
}

/// 基础粒子演示
class BasicParticleDemo extends StatefulWidget {
  const BasicParticleDemo({super.key});

  @override
  State<BasicParticleDemo> createState() => _BasicParticleDemoState();
}

class _BasicParticleDemoState extends State<BasicParticleDemo>
    with SingleTickerProviderStateMixin {
  late AnimationController _controller;
  final List<Particle> _particles = [];
  final Random _random = Random();

  @override
  void initState() {
    super.initState();
    _controller = AnimationController(
      vsync: this,
      duration: const Duration(seconds: 1),
    )..repeat();

    for (int i = 0; i < 100; i++) {
      _particles.add(Particle(
        position: Vector2D(_random.nextDouble() * 400, _random.nextDouble() * 400),
        velocity: Vector2D.fromAngle(_random.nextDouble() * pi * 2, 50),
        color: HSVColor.fromAHSV(1, _random.nextDouble() * 360, 0.8, 1).toColor(),
        maxLife: 5 + _random.nextDouble() * 5,
      ));
    }
  }

  @override
  void dispose() {
    _controller.dispose();
    super.dispose();
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(title: const Text('基础粒子')),
      body: AnimatedBuilder(
        animation: _controller,
        builder: (context, child) {
          for (final p in _particles) {
            p.update(0.016);
            if (p.position.x < 0 || p.position.x > 400) p.velocity.x *= -1;
            if (p.position.y < 0 || p.position.y > 400) p.velocity.y *= -1;
          }

          return CustomPaint(
            painter: BasicParticlePainter(_particles),
            size: Size.infinite,
          );
        },
      ),
    );
  }
}

class BasicParticlePainter extends CustomPainter {
  final List<Particle> particles;
  BasicParticlePainter(this.particles);

  @override
  void paint(Canvas canvas, Size size) {
    canvas.drawRect(Rect.fromLTWH(0, 0, size.width, size.height),
        Paint()..color = const Color(0xFF0a0a1a));

    for (final p in particles) {
      canvas.drawCircle(
        Offset(p.position.x, p.position.y),
        p.radius * p.lifeRatio,
        Paint()..color = p.color.withOpacity(p.lifeRatio),
      );
    }
  }

  @override
  bool shouldRepaint(covariant BasicParticlePainter old) => true;
}

/// 引力场演示
class GravityFieldDemo extends StatefulWidget {
  const GravityFieldDemo({super.key});

  @override
  State<GravityFieldDemo> createState() => _GravityFieldDemoState();
}

class _GravityFieldDemoState extends State<GravityFieldDemo>
    with SingleTickerProviderStateMixin {
  late AnimationController _controller;
  final ParticleSystem _system = ParticleSystem(maxParticles: 300);
  final Random _random = Random();
  late GravityField _gravityField;

  @override
  void initState() {
    super.initState();
    _controller = AnimationController(
      vsync: this,
      duration: const Duration(seconds: 1),
    )..repeat();

    _gravityField = GravityField(Vector2D(200, 200), 300, 300);
    _system.addForceField(_gravityField);
  }

  @override
  void dispose() {
    _controller.dispose();
    super.dispose();
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(title: const Text('引力场')),
      body: GestureDetector(
        onPanUpdate: (details) {
          _gravityField.position = Vector2D(
            details.localPosition.dx,
            details.localPosition.dy,
          );
        },
        child: AnimatedBuilder(
          animation: _controller,
          builder: (context, child) {
            if (_system.particles.length < 200) {
              _system.addParticle(Particle(
                position: Vector2D(
                  _random.nextDouble() * 400,
                  _random.nextDouble() * 400,
                ),
                velocity: Vector2D.fromAngle(_random.nextDouble() * pi * 2, 20),
                color: HSVColor.fromAHSV(1, _random.nextDouble() * 360, 0.8, 1).toColor(),
                maxLife: 8,
              ));
            }

            _system.update(0.016);

            return CustomPaint(
              painter: GravityPainter(_system, _gravityField),
              size: Size.infinite,
            );
          },
        ),
      ),
    );
  }
}

class GravityPainter extends CustomPainter {
  final ParticleSystem system;
  final GravityField field;

  GravityPainter(this.system, this.field);

  @override
  void paint(Canvas canvas, Size size) {
    canvas.drawRect(Rect.fromLTWH(0, 0, size.width, size.height),
        Paint()..color = const Color(0xFF050510));

    canvas.drawCircle(
      Offset(field.position.x, field.position.y),
      field.range,
      Paint()..color = Colors.blue.withOpacity(0.1)..style = PaintingStyle.stroke,
    );

    canvas.drawCircle(
      Offset(field.position.x, field.position.y),
      10,
      Paint()..color = Colors.blue,
    );

    for (final p in system.particles) {
      canvas.drawCircle(
        Offset(p.position.x, p.position.y),
        p.radius * p.lifeRatio,
        Paint()..color = p.color.withOpacity(p.lifeRatio * 0.8),
      );
    }
  }

  @override
  bool shouldRepaint(covariant GravityPainter old) => true;
}

/// 斥力场演示
class RepulsionFieldDemo extends StatefulWidget {
  const RepulsionFieldDemo({super.key});

  @override
  State<RepulsionFieldDemo> createState() => _RepulsionFieldDemoState();
}

class _RepulsionFieldDemoState extends State<RepulsionFieldDemo>
    with SingleTickerProviderStateMixin {
  late AnimationController _controller;
  final ParticleSystem _system = ParticleSystem(maxParticles: 200);
  final Random _random = Random();

  @override
  void initState() {
    super.initState();
    _controller = AnimationController(
      vsync: this,
      duration: const Duration(seconds: 1),
    )..repeat();

    _system.addForceField(RepulsionField(Vector2D(100, 200), 5000, 80));
    _system.addForceField(RepulsionField(Vector2D(300, 200), 5000, 80));
  }

  @override
  void dispose() {
    _controller.dispose();
    super.dispose();
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(title: const Text('斥力场')),
      body: AnimatedBuilder(
        animation: _controller,
        builder: (context, child) {
          if (_system.particles.length < 150) {
            _system.addParticle(Particle(
              position: Vector2D(200, 100),
              velocity: Vector2D.fromAngle(_random.nextDouble() * pi * 2, 30),
              color: HSVColor.fromAHSV(1, (_random.nextDouble() * 60 + 330) % 360, 0.8, 1).toColor(),
              maxLife: 6,
            ));
          }

          _system.update(0.016);

          return CustomPaint(
            painter: RepulsionPainter(_system),
            size: Size.infinite,
          );
        },
      ),
    );
  }
}

class RepulsionPainter extends CustomPainter {
  final ParticleSystem system;
  RepulsionPainter(this.system);

  @override
  void paint(Canvas canvas, Size size) {
    canvas.drawRect(Rect.fromLTWH(0, 0, size.width, size.height),
        Paint()..color = const Color(0xFF100510));

    for (final f in system.forceFields) {
      if (f is RepulsionField) {
        canvas.drawCircle(
          Offset(f.position.x, f.position.y),
          f.range,
          Paint()..color = Colors.red.withOpacity(0.2)..style = PaintingStyle.stroke,
        );
        canvas.drawCircle(
          Offset(f.position.x, f.position.y),
          8,
          Paint()..color = Colors.red,
        );
      }
    }

    for (final p in system.particles) {
      canvas.drawCircle(
        Offset(p.position.x, p.position.y),
        p.radius * p.lifeRatio,
        Paint()..color = p.color.withOpacity(p.lifeRatio * 0.8),
      );
    }
  }

  @override
  bool shouldRepaint(covariant RepulsionPainter old) => true;
}

/// 涡流场演示
class VortexFieldDemo extends StatefulWidget {
  const VortexFieldDemo({super.key});

  @override
  State<VortexFieldDemo> createState() => _VortexFieldDemoState();
}

class _VortexFieldDemoState extends State<VortexFieldDemo>
    with SingleTickerProviderStateMixin {
  late AnimationController _controller;
  final ParticleSystem _system = ParticleSystem(maxParticles: 300, damping: 0.995);
  final Random _random = Random();

  @override
  void initState() {
    super.initState();
    _controller = AnimationController(
      vsync: this,
      duration: const Duration(seconds: 1),
    )..repeat();

    _system.addForceField(VortexField(Vector2D(150, 200), 30, 80, 150));
    _system.addForceField(VortexField(Vector2D(250, 200), 30, -80, 150));
  }

  @override
  void dispose() {
    _controller.dispose();
    super.dispose();
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(title: const Text('涡流场')),
      body: AnimatedBuilder(
        animation: _controller,
        builder: (context, child) {
          if (_system.particles.length < 200) {
            _system.addParticle(Particle(
              position: Vector2D(_random.nextDouble() * 400, _random.nextDouble() * 400),
              velocity: Vector2D.fromAngle(_random.nextDouble() * pi * 2, 10),
              color: HSVColor.fromAHSV(1, (_random.nextDouble() * 120 + 260) % 360, 0.8, 1).toColor(),
              maxLife: 10,
            ));
          }

          _system.update(0.016);

          return CustomPaint(
            painter: VortexPainter(_system),
            size: Size.infinite,
          );
        },
      ),
    );
  }
}

class VortexPainter extends CustomPainter {
  final ParticleSystem system;
  VortexPainter(this.system);

  @override
  void paint(Canvas canvas, Size size) {
    canvas.drawRect(Rect.fromLTWH(0, 0, size.width, size.height),
        Paint()..color = const Color(0xFF0a0515));

    for (final f in system.forceFields) {
      if (f is VortexField) {
        canvas.drawCircle(
          Offset(f.position.x, f.position.y),
          f.range,
          Paint()..color = Colors.purple.withOpacity(0.15)..style = PaintingStyle.stroke,
        );
        canvas.drawCircle(
          Offset(f.position.x, f.position.y),
          6,
          Paint()..color = Colors.purple,
        );
      }
    }

    for (final p in system.particles) {
      canvas.drawCircle(
        Offset(p.position.x, p.position.y),
        p.radius * p.lifeRatio,
        Paint()..color = p.color.withOpacity(p.lifeRatio * 0.7),
      );
    }
  }

  @override
  bool shouldRepaint(covariant VortexPainter old) => true;
}

/// 音乐引力场演示
class MusicGravityDemo extends StatefulWidget {
  const MusicGravityDemo({super.key});

  @override
  State<MusicGravityDemo> createState() => _MusicGravityDemoState();
}

class _MusicGravityDemoState extends State<MusicGravityDemo> with TickerProviderStateMixin {
  late AnimationController _animController;
  late AudioPlayer _audioPlayer;
  final ParticleSystem _system = ParticleSystem(maxParticles: 500);
  final Random _random = Random();
  Float32List _audioData = Float32List(128);
  bool _isPlaying = false;
  Duration _position = Duration.zero;
  Duration _duration = Duration.zero;
  double _energy = 0;
  double _bass = 0;

  late GravityField _centerGravity;

  static const String _audioUrl =
      'https://www.soundhelix.com/examples/mp3/SoundHelix-Song-1.mp3';

  @override
  void initState() {
    super.initState();
    _initAudio();
    _animController = AnimationController(
      vsync: this,
      duration: const Duration(milliseconds: 16),
    )..repeat();
    _animController.addListener(_update);

    _centerGravity = GravityField(Vector2D(200, 200), 300, 300);
    _system.addForceField(_centerGravity);
  }

  Future<void> _initAudio() async {
    _audioPlayer = AudioPlayer();

    final session = await AudioSession.instance;
    await session.configure(const AudioSessionConfiguration.music());

    _audioPlayer.playerStateStream.listen((state) {
      setState(() => _isPlaying = state.playing);
    });

    _audioPlayer.positionStream.listen((pos) {
      setState(() => _position = pos);
    });

    _audioPlayer.durationStream.listen((dur) {
      setState(() => _duration = dur ?? Duration.zero);
    });

    try {
      await _audioPlayer.setUrl(_audioUrl);
    } catch (e) {
      debugPrint('加载音频失败: $e');
    }
  }

  void _update() {
    final time = DateTime.now().millisecondsSinceEpoch / 1000.0;

    for (int i = 0; i < 128; i++) {
      if (_isPlaying) {
        final freq = (i / 128) * 8 + 1;
        final wave = sin(time * freq) * 0.4 + sin(time * freq * 1.5) * 0.3;
        final bassBoost = i < 32 ? 0.3 : 0;
        _audioData[i] = _audioData[i] * 0.85 + (wave + bassBoost) * 0.15;
      } else {
        _audioData[i] *= 0.95;
      }
    }

    double totalEnergy = 0, bassEnergy = 0;
    for (int i = 0; i < 128; i++) {
      totalEnergy += _audioData[i].abs();
      if (i < 32) bassEnergy += _audioData[i].abs();
    }
    _energy = totalEnergy / 128;
    _bass = bassEnergy / 32;

    _centerGravity.strength = 200 + _bass * 500;

    if (_system.particles.length < 300) {
      final hue = ((time * 30) % 360).abs();
      _system.addParticle(Particle(
        position: Vector2D(200 + sin(time * 2) * 50, 200 + cos(time * 2) * 50),
        velocity: Vector2D.fromAngle(time * 3, 30 + _energy * 80),
        color: HSVColor.fromAHSV(1, hue, 0.8, 1).toColor(),
        radius: 3 + _bass * 4,
        maxLife: 5,
      ));
    }

    _system.update(0.016);
    setState(() {});
  }

  @override
  void dispose() {
    _animController.dispose();
    _audioPlayer.dispose();
    super.dispose();
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(title: const Text('音乐引力场')),
      body: Stack(
        children: [
          CustomPaint(
            painter: MusicGravityPainter(_system, _centerGravity, _energy, _isPlaying),
            size: Size.infinite,
          ),
          Positioned(
            bottom: 30,
            left: 20,
            right: 20,
            child: _buildControls(),
          ),
        ],
      ),
    );
  }

  Widget _buildControls() {
    return Container(
      padding: const EdgeInsets.all(16),
      decoration: BoxDecoration(
        color: Colors.black.withOpacity(0.7),
        borderRadius: BorderRadius.circular(16),
      ),
      child: Column(
        mainAxisSize: MainAxisSize.min,
        children: [
          const Text('🎵 SoundHelix - Song 1',
            style: TextStyle(color: Colors.white, fontSize: 14)),
          const SizedBox(height: 12),
          Slider(
            value: _duration.inMilliseconds > 0
                ? _position.inMilliseconds.toDouble().clamp(0, _duration.inMilliseconds.toDouble())
                : 0,
            max: _duration.inMilliseconds > 0 ? _duration.inMilliseconds.toDouble() : 1,
            onChanged: (v) => _audioPlayer.seek(Duration(milliseconds: v.toInt())),
          ),
          IconButton(
            icon: Icon(_isPlaying ? Icons.pause : Icons.play_arrow,
              color: Colors.indigo, size: 40),
            onPressed: () => _isPlaying ? _audioPlayer.pause() : _audioPlayer.play(),
          ),
        ],
      ),
    );
  }
}

class MusicGravityPainter extends CustomPainter {
  final ParticleSystem system;
  final GravityField field;
  final double energy;
  final bool isPlaying;

  MusicGravityPainter(this.system, this.field, this.energy, this.isPlaying);

  @override
  void paint(Canvas canvas, Size size) {
    canvas.drawRect(Rect.fromLTWH(0, 0, size.width, size.height),
        Paint()..color = Color.lerp(const Color(0xFF050510), const Color(0xFF100520), energy)!);

    canvas.drawCircle(
      Offset(field.position.x, field.position.y),
      field.range,
      Paint()..color = Colors.indigo.withOpacity(0.1 + energy * 0.1)
               ..style = PaintingStyle.stroke,
    );

    final centerPaint = Paint()
      ..shader = RadialGradient(
        colors: [Colors.indigo.withOpacity(0.8), Colors.indigo.withOpacity(0)],
      ).createShader(Rect.fromCircle(
        center: Offset(field.position.x, field.position.y),
        radius: 30,
      ));
    canvas.drawCircle(Offset(field.position.x, field.position.y), 30, centerPaint);

    for (final p in system.particles) {
      final paint = Paint()..color = p.color.withOpacity(p.lifeRatio * 0.8);
      if (isPlaying && p.velocity.magnitude > 30) {
        paint.maskFilter = const MaskFilter.blur(BlurStyle.normal, 2);
      }
      canvas.drawCircle(
        Offset(p.position.x, p.position.y),
        p.radius * p.lifeRatio,
        paint,
      );
    }
  }

  @override
  bool shouldRepaint(covariant MusicGravityPainter old) => true;
}

/// 综合演示
class FullGravityDemo extends StatefulWidget {
  const FullGravityDemo({super.key});

  @override
  State<FullGravityDemo> createState() => _FullGravityDemoState();
}

class _FullGravityDemoState extends State<FullGravityDemo> with TickerProviderStateMixin {
  late AnimationController _animController;
  late AudioPlayer _audioPlayer;
  final ParticleSystem _system = ParticleSystem(maxParticles: 600, damping: 0.98);
  final Random _random = Random();
  Float32List _audioData = Float32List(128);
  bool _isPlaying = false;
  Duration _position = Duration.zero;
  Duration _duration = Duration.zero;
  double _energy = 0, _bass = 0, _mid = 0, _treble = 0;

  late GravityField _centerGravity;
  late VortexField _vortex1, _vortex2;

  static const String _audioUrl =
      'https://www.soundhelix.com/examples/mp3/SoundHelix-Song-1.mp3';

  @override
  void initState() {
    super.initState();
    _initAudio();
    _animController = AnimationController(
      vsync: this,
      duration: const Duration(milliseconds: 16),
    )..repeat();
    _animController.addListener(_update);

    _centerGravity = GravityField(Vector2D(200, 200), 300, 250);
    _vortex1 = VortexField(Vector2D(120, 200), 20, 60, 120);
    _vortex2 = VortexField(Vector2D(280, 200), 20, -60, 120);

    _system.addForceField(_centerGravity);
    _system.addForceField(_vortex1);
    _system.addForceField(_vortex2);

    _system.addForceField(RepulsionField(Vector2D(30, 30), 3000, 60));
    _system.addForceField(RepulsionField(Vector2D(370, 30), 3000, 60));
    _system.addForceField(RepulsionField(Vector2D(30, 370), 3000, 60));
    _system.addForceField(RepulsionField(Vector2D(370, 370), 3000, 60));
  }

  Future<void> _initAudio() async {
    _audioPlayer = AudioPlayer();
    final session = await AudioSession.instance;
    await session.configure(const AudioSessionConfiguration.music());

    _audioPlayer.playerStateStream.listen((s) => setState(() => _isPlaying = s.playing));
    _audioPlayer.positionStream.listen((p) => setState(() => _position = p));
    _audioPlayer.durationStream.listen((d) => setState(() => _duration = d ?? Duration.zero));

    try {
      await _audioPlayer.setUrl(_audioUrl);
    } catch (e) {
      debugPrint('加载失败: $e');
    }
  }

  void _update() {
    final time = DateTime.now().millisecondsSinceEpoch / 1000.0;

    for (int i = 0; i < 128; i++) {
      if (_isPlaying) {
        final freq = (i / 128) * 8 + 1;
        final wave = sin(time * freq) * 0.4 + sin(time * freq * 1.5) * 0.3;
        final bass = i < 32 ? 0.3 : 0;
        _audioData[i] = _audioData[i] * 0.85 + (wave + bass) * 0.15;
      } else {
        _audioData[i] *= 0.95;
      }
    }

    double total = 0, bassE = 0, midE = 0, trebleE = 0;
    for (int i = 0; i < 128; i++) {
      final v = _audioData[i].abs();
      total += v;
      if (i < 32) bassE += v;
      else if (i < 96) midE += v;
      else trebleE += v;
    }
    _energy = total / 128;
    _bass = bassE / 32;
    _mid = midE / 64;
    _treble = trebleE / 32;

    _centerGravity.strength = 200 + _bass * 400;
    _centerGravity.position = Vector2D(
      200 + sin(time * 0.5) * 30 * _energy,
      200 + cos(time * 0.5) * 30 * _energy,
    );
    _vortex1.angularStrength = 40 + _mid * 100;
    _vortex2.angularStrength = -40 - _mid * 100;

    if (_system.particles.length < 400) {
      final hue = (time * 25) % 360;
      _system.addParticle(Particle(
        position: Vector2D(
          200 + sin(time * 2) * 60,
          200 + cos(time * 2) * 60,
        ),
        velocity: Vector2D.fromAngle(time * 3, 20 + _energy * 60),
        color: HSVColor.fromAHSV(1, hue, 0.8, 1).toColor(),
        radius: 2 + _bass * 3,
        maxLife: 6,
      ));
    }

    _system.update(0.016);
    setState(() {});
  }

  @override
  void dispose() {
    _animController.dispose();
    _audioPlayer.dispose();
    super.dispose();
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      body: Stack(
        children: [
          CustomPaint(
            painter: FullGravityPainter(_system, _centerGravity, _vortex1, _vortex2,
                _energy, _isPlaying),
            size: Size.infinite,
          ),
          Positioned(
            top: 40,
            left: 20,
            child: SafeArea(
              child: IconButton(
                icon: const Icon(Icons.arrow_back, color: Colors.white),
                onPressed: () => Navigator.pop(context),
              ),
            ),
          ),
          Positioned(
            bottom: 40,
            left: 20,
            right: 20,
            child: _buildControls(),
          ),
        ],
      ),
    );
  }

  Widget _buildControls() {
    return Container(
      padding: const EdgeInsets.all(20),
      decoration: BoxDecoration(
        color: Colors.black.withOpacity(0.7),
        borderRadius: BorderRadius.circular(20),
        border: Border.all(color: Colors.indigo.withOpacity(0.3)),
      ),
      child: Column(
        mainAxisSize: MainAxisSize.min,
        children: [
          const Text('🌌 粒子引力场',
            style: TextStyle(color: Colors.white, fontSize: 18, fontWeight: FontWeight.bold)),
          const SizedBox(height: 4),
          const Text('SoundHelix - Song 1',
            style: TextStyle(color: Colors.white70, fontSize: 14)),
          const SizedBox(height: 16),
          Slider(
            value: _duration.inMilliseconds > 0
                ? _position.inMilliseconds.toDouble().clamp(0, _duration.inMilliseconds.toDouble())
                : 0,
            max: _duration.inMilliseconds > 0 ? _duration.inMilliseconds.toDouble() : 1,
            onChanged: (v) => _audioPlayer.seek(Duration(milliseconds: v.toInt())),
          ),
          Row(
            mainAxisAlignment: MainAxisAlignment.center,
            children: [
              IconButton(
                icon: const Icon(Icons.replay_10, color: Colors.white70),
                onPressed: () {
                  final newPos = _position - const Duration(seconds: 10);
                  _audioPlayer.seek(newPos.isNegative ? Duration.zero : newPos);
                },
              ),
              const SizedBox(width: 20),
              Container(
                decoration: BoxDecoration(
                  shape: BoxShape.circle,
                  gradient: LinearGradient(
                    colors: [Colors.indigo.shade400, Colors.indigo.shade700],
                  ),
                ),
                child: IconButton(
                  icon: Icon(_isPlaying ? Icons.pause : Icons.play_arrow,
                    color: Colors.white, size: 36),
                  onPressed: () => _isPlaying ? _audioPlayer.pause() : _audioPlayer.play(),
                ),
              ),
              const SizedBox(width: 20),
              IconButton(
                icon: const Icon(Icons.forward_10, color: Colors.white70),
                onPressed: () {
                  final newPos = _position + const Duration(seconds: 10);
                  _audioPlayer.seek(newPos > _duration ? _duration : newPos);
                },
              ),
            ],
          ),
        ],
      ),
    );
  }
}

class FullGravityPainter extends CustomPainter {
  final ParticleSystem system;
  final GravityField gravity;
  final VortexField vortex1, vortex2;
  final double energy;
  final bool isPlaying;

  FullGravityPainter(this.system, this.gravity, this.vortex1, this.vortex2,
      this.energy, this.isPlaying);

  @override
  void paint(Canvas canvas, Size size) {
    canvas.drawRect(Rect.fromLTWH(0, 0, size.width, size.height),
        Paint()..color = Color.lerp(const Color(0xFF050510), const Color(0xFF150525), energy)!);

    canvas.drawCircle(
      Offset(gravity.position.x, gravity.position.y),
      gravity.range,
      Paint()..color = Colors.indigo.withOpacity(0.08 + energy * 0.08)
               ..style = PaintingStyle.stroke,
    );

    final centerPaint = Paint()
      ..shader = RadialGradient(
        colors: [Colors.indigo.withOpacity(0.6), Colors.indigo.withOpacity(0)],
      ).createShader(Rect.fromCircle(
        center: Offset(gravity.position.x, gravity.position.y),
        radius: 25,
      ));
    canvas.drawCircle(Offset(gravity.position.x, gravity.position.y), 25, centerPaint);
    canvas.drawCircle(Offset(gravity.position.x, gravity.position.y), 5,
        Paint()..color = Colors.white);

    for (final v in [vortex1, vortex2]) {
      canvas.drawCircle(
        Offset(v.position.x, v.position.y),
        v.range,
        Paint()..color = Colors.purple.withOpacity(0.1)..style = PaintingStyle.stroke,
      );
      canvas.drawCircle(
        Offset(v.position.x, v.position.y),
        6,
        Paint()..color = Colors.purple.withOpacity(0.8),
      );
    }

    for (final f in system.forceFields) {
      if (f is RepulsionField) {
        canvas.drawCircle(
          Offset(f.position.x, f.position.y),
          f.range,
          Paint()..color = Colors.red.withOpacity(0.1 + energy * 0.1)
                   ..style = PaintingStyle.stroke,
        );
        canvas.drawCircle(
          Offset(f.position.x, f.position.y),
          5,
          Paint()..color = Colors.red.withOpacity(0.6),
        );
      }
    }

    for (final p in system.particles) {
      final paint = Paint()..color = p.color.withOpacity(p.lifeRatio * 0.75);
      if (isPlaying && p.velocity.magnitude > 40) {
        paint.maskFilter = const MaskFilter.blur(BlurStyle.normal, 2);
      }
      canvas.drawCircle(
        Offset(p.position.x, p.position.y),
        p.radius * (0.5 + p.lifeRatio * 0.5),
        paint,
      );
    }
  }

  @override
  bool shouldRepaint(covariant FullGravityPainter old) => true;
}

---

📝 五、总结

本篇文章深入探讨了粒子物理系统在音乐可视化中的应用，从牛顿万有引力定律到多种力场的实现，构建了具有"宇宙感"的粒子动画效果。

✅ 核心知识点回顾

知识点	说明
🌌粒子系统	位置、速度、加速度、生命周期
🔵引力场	F ∝ 1/r²，聚集效果
🔴斥力场	F ∝ -1/r²，扩散效果
🟣涡流场	切向力，旋转效果
🎵音频驱动	低音控制引力，中频控制涡流
🔊网络音乐	just_audio_ohos 在线播放

⭐ 最佳实践要点

• ✅ 使用欧拉积分更新粒子状态
• ✅ 设置最小距离避免力过大
• ✅ 添加阻尼使系统稳定
• ✅ 粒子生命周期管理避免内存泄漏

🚀 进阶方向

• 🔮 使用 Verlet 积分提升精度
• ✨ 添加粒子间相互作用力
• 👆 触摸交互创建临时力场
• ⚡ 使用 Isolate 并行计算

---
