华为昇腾910B服务器上部署Qwen3-30B-A3B并使用EvalScope推理性能测试

摘要：本文介绍了在华为昇腾910B显卡上使用MindIE和vllm-ascend推理引擎运行Qwen3-30B-A3B大模型的完整流程。测试环境配置8张910B显卡，其中0-3卡供MindIE使用，4-7卡供vllm-ascend使用。详细说明了MindIE的容器部署、配置修改和服务启动步骤，以及vllm-ascend的快速部署方法。使用EvalScope工具进行性能测试，结果显示在1024输入上

INSNNP_LZM

365人浏览 · 2025-11-19 14:07:14

INSNNP_LZM · 2025-11-19 14:07:14 发布

使用 MindIE、vllm-ascend 推理引擎在华为昇腾910B显卡上运行 Qwen3-30B-A3B 模型，然后简单测试下推理性能

一、准备

1.1 环境信息


模型	Qwen3-30B-A3B	MindIE 运行该模型需要至少2张卡，推荐4张
服务器型号	Atlas 800I A2	1台
显卡	910B4	64G/张
驱动	>=24.1.0
MindIE	>=2.1.RC1
vllm-ascend	v0.11.0rc0

服务器一共8张卡，0-3 给 MindIE 使用，4-7 给 vllm-ascend 使用

1.2 模型准备

modelscope download --model Qwen/Qwen3-30B-A3B --local_dir /model/Qwen3-30B-A3B

chmod -R 750 /model/Qwen3-30B-A3B

Bash

二、使用 MindIE 运行

2.1 启动容器

docker run -itd --privileged --name=qwen3-30b-a3b-mindie --net=host --shm-size=500g \
    --device=/dev/davinci0 \
    --device=/dev/davinci1 \
    --device=/dev/davinci2 \
    --device=/dev/davinci3 \
    --device=/dev/davinci_manager \
    --device=/dev/devmm_svm \
    --device=/dev/hisi_hdc \
    -v /usr/local/Ascend/driver:/usr/local/Ascend/driver \
    -v /usr/local/Ascend/add-ons/:/usr/local/Ascend/add-ons/ \
    -v /usr/local/sbin/:/usr/local/sbin/ \
    -v /var/log/npu/slog/:/var/log/npu/slog \
    -v /var/log/npu/profiling/:/var/log/npu/profiling \
    -v /var/log/npu/dump/:/var/log/npu/dump \
    -v /var/log/npu/:/usr/slog \
    -v /etc/hccn.conf:/etc/hccn.conf \
    -v /model:/model \
    swr.cn-south-1.myhuaweicloud.com/ascendhub/mindie:2.1.RC1-800I-A2-py311-openeuler24.03-lts \
    /bin/bash

Bash

2.2 修改配置

docker exec -it qwen3-30b-a3b-mindie bash

cd /usr/local/Ascend/mindie/latest/mindie-service
vim conf/config.json

Bash

必须修改的参数如下（没有按照在配置文件中的顺序），其他参数可根据需要自行修改

"httpsEnabled": false，禁用 HTTPS
"npuDeviceIds": [[0,1,2,3]]，NPU 卡号，下标从0开始
"modelName": qwen3-30b-a3b，模型名称，后续调用模型服务时使用
"modelWeightPath": /model/Qwen3-30B-A3B，挂载到容器内模型权重路径
"worldSize": 4，模型使用的 NPU 卡总数量

ASCEND_RT_VISIBLE_DEVICES选择物理卡，npuDeviceIds使用逻辑卡。即无论 ASCEND_RT_VISIBLE_DEVICES选择了什么卡，npuDeviceIds下标一律从0开始。

NPU 可以被多个容器挂载，但只能被一个容器使用。

测试时使用的配置文件如下：

{
    "Version" : "1.0.0",

    "ServerConfig" :
    {
        "ipAddress" : "0.0.0.0",
        "managementIpAddress" : "127.0.0.2",
        "port" : 1025,
        "managementPort" : 1026,
        "metricsPort" : 1027,
        "allowAllZeroIpListening" : true,
        "maxLinkNum" : 1000,
        "httpsEnabled" : false,
        "fullTextEnabled" : false,
        "tlsCaPath" : "security/ca/",
        "tlsCaFile" : ["ca.pem"],
        "tlsCert" : "security/certs/server.pem",
        "tlsPk" : "security/keys/server.key.pem",
        "tlsPkPwd" : "security/pass/key_pwd.txt",
        "tlsCrlPath" : "security/certs/",
        "tlsCrlFiles" : ["server_crl.pem"],
        "managementTlsCaFile" : ["management_ca.pem"],
        "managementTlsCert" : "security/certs/management/server.pem",
        "managementTlsPk" : "security/keys/management/server.key.pem",
        "managementTlsPkPwd" : "security/pass/management/key_pwd.txt",
        "managementTlsCrlPath" : "security/management/certs/",
        "managementTlsCrlFiles" : ["server_crl.pem"],
        "kmcKsfMaster" : "tools/pmt/master/ksfa",
        "kmcKsfStandby" : "tools/pmt/standby/ksfb",
        "inferMode" : "standard",
        "interCommTLSEnabled" : true,
        "interCommPort" : 1121,
        "interCommTlsCaPath" : "security/grpc/ca/",
        "interCommTlsCaFiles" : ["ca.pem"],
        "interCommTlsCert" : "security/grpc/certs/server.pem",
        "interCommPk" : "security/grpc/keys/server.key.pem",
        "interCommPkPwd" : "security/grpc/pass/key_pwd.txt",
        "interCommTlsCrlPath" : "security/grpc/certs/",
        "interCommTlsCrlFiles" : ["server_crl.pem"],
        "openAiSupport" : "vllm",
        "tokenTimeout" : 600,
        "e2eTimeout" : 600,
        "distDPServerEnabled":false
    },

    "BackendConfig" : {
        "backendName" : "mindieservice_llm_engine",
        "modelInstanceNumber" : 1,
        "npuDeviceIds" : [[0,1,2,3]],
        "tokenizerProcessNumber" : 8,
        "multiNodesInferEnabled" : false,
        "multiNodesInferPort" : 1120,
        "interNodeTLSEnabled" : true,
        "interNodeTlsCaPath" : "security/grpc/ca/",
        "interNodeTlsCaFiles" : ["ca.pem"],
        "interNodeTlsCert" : "security/grpc/certs/server.pem",
        "interNodeTlsPk" : "security/grpc/keys/server.key.pem",
        "interNodeTlsPkPwd" : "security/grpc/pass/mindie_server_key_pwd.txt",
        "interNodeTlsCrlPath" : "security/grpc/certs/",
        "interNodeTlsCrlFiles" : ["server_crl.pem"],
        "interNodeKmcKsfMaster" : "tools/pmt/master/ksfa",
        "interNodeKmcKsfStandby" : "tools/pmt/standby/ksfb",
        "ModelDeployConfig" :
        {
            "maxSeqLen" : 8192,
            "maxInputTokenLen" : 6144,
            "truncation" : false,
            "ModelConfig" : [
                {
                    "modelInstanceType" : "Standard",
                    "modelName" : "qwen3-30b-a3b",
                    "modelWeightPath" : "/model/Qwen3-30B-A3B",
                    "worldSize" : 4,
                    "cpuMemSize" : 5,
                    "npuMemSize" : -1,
                    "backendType" : "atb",
                    "trustRemoteCode" : false,
                    "async_scheduler_wait_time": 120,
                    "kv_trans_timeout": 10,
                    "kv_link_timeout": 1080
                }
            ]
        },

        "ScheduleConfig" :
        {
            "templateType" : "Standard",
            "templateName" : "Standard_LLM",
            "cacheBlockSize" : 128,

            "maxPrefillBatchSize" : 10,
            "maxPrefillTokens" : 6144,
            "prefillTimeMsPerReq" : 150,
            "prefillPolicyType" : 0,

            "decodeTimeMsPerReq" : 50,
            "decodePolicyType" : 0,

            "maxBatchSize" : 200,
            "maxIterTimes" : 2048,
            "maxPreemptCount" : 0,
            "supportSelectBatch" : false,
            "maxQueueDelayMicroseconds" : 5000
        }
    }
}

JSON

2.3 启动模型服务

docker exec -it qwen3-30b-a3b-mindie bash

export ASCEND_RT_VISIBLE_DEVICES=0,1,2,3
cd /usr/local/Ascend/mindie/latest/mindie-service
./bin/mindieservice_daemon

Bash

日志中输出 Daemon start success!表示模型服务已经正常启动

三、使用 vllm-ascend 运行

使用 vllm-ascend 运行模型比较方便，启动容器时将 4-7 卡挂载到容器，模型服务将会使用 4-7 卡

export IMAGE=quay.io/ascend/vllm-ascend:v0.11.0rc0
docker run -itd \
    --name qwen3-30b-a3b-vllm-ascend \
    --shm-size=1g \
    --device /dev/davinci4 \
    --device /dev/davinci5 \
    --device /dev/davinci6 \
    --device /dev/davinci7 \
    --device /dev/davinci_manager \
    --device /dev/devmm_svm \
    --device /dev/hisi_hdc \
    -v /usr/local/dcmi:/usr/local/dcmi \
    -v /usr/local/bin/npu-smi:/usr/local/bin/npu-smi \
    -v /usr/local/Ascend/driver/lib64/:/usr/local/Ascend/driver/lib64/ \
    -v /usr/local/Ascend/driver/version.info:/usr/local/Ascend/driver/version.info \
    -v /etc/ascend_install.info:/etc/ascend_install.info \
    -v /root/.cache:/root/.cache \
    -v /model:/model \
    -p 8000:8000 \
    -e PYTORCH_NPU_ALLOC_CONF=max_split_size_mb:256 \
    -e VLLM_USE_MODELSCOPE=True \
    -it $IMAGE \
    vllm serve /model/Qwen3-30B-A3B --served-model-name qwen3-30b-a3b --host 0.0.0.0 --port 8000 --tensor-parallel-size 4 --enable_expert_parallel --gpu-memory-utilization 0.9 --enable-prefix-caching --enable-chunked-prefill

Bash

四、推理性能测试

4.1 测试工具

测试工具选择 EvalScope，示例脚本如下：

EvalScope 支持命令行、Python两种执行方式，这两种方式对结果不会有影响，这里使用 Python 脚本的方式，再自行写脚本批量执行

# llm-bench.py
from evalscope.perf.main import run_perf_benchmark
from evalscope.perf.arguments import Arguments

task_cfg = Arguments(
    parallel=[1],
    number=[10],
    model='qwen3-30b-a3b',
    url='http://127.0.0.1:8000/v1/chat/completions',
    api='openai',
    dataset='random',
    min_tokens=1024,
    max_tokens=1024,
    prefix_length=0,
    min_prompt_length=1024,
    max_prompt_length=1024,
    tokenizer_path='/model/Qwen3-30B-A3B',
    extra_args={'ignore_eos': True}
)

results = run_perf_benchmark(task_cfg)

Bash

执行：

python3 llm-bench.py

Bash

4.2 测试结果

测试结果如下，从结果上来看，MindIE 整体表现要比 vllm-ascend 好一些

输入上下文为1024，输出上下文为256

到448并发后 vllm-ascend 异常退出，所以暂时只测试以下情况

结果仅供参考

		MindIE	MindIE	MindIE	vllm-ascend	vllm-ascend	vllm-ascend
batch size并发数	requests 请求数	TTFT(s)	TPOT(s)	throughout(tokens/s)	TTFT(s)	TPOT(s)	throughout(tokens/s)
1	50	0.0958	0.0219	229.0896	0.2579	0.0216	225.4876
16	50	0.4537	0.0284	2198.1873	2.2589	0.0319	1623.3467
32	64	0.7763	0.0372	3988.11	5.4252	0.0336	2922.9758
64	128	1.3651	0.0506	5727.4234	8.9482	0.0471	3900.7664
96	192	1.9668	0.061	6987.6632	12.3918	0.0593	4449.3021
128	256	2.5768	0.0708	7896.7329	17.6229	0.0733	4491.8562
192	384	3.7235	0.096	8679.6975	28.9566	0.0905	4709.636
224	448	3.9525	0.1051	8017.7596	33.6394	0.1131	4579.7825
256	512	4.1468	0.1167	8398.7053	28.033	0.1085	5866.5547
320	640	4.7421	0.1451	8281.9079	35.1066	0.1014	5879.3744
384	768	5.5375	0.1748	8702.9784	39.3735	0.1053	6652.2664
448	896	6.0939	0.2022	8498.057	56.4764	0.1272	4731.1409
